NEC Business Solutions Ltd Xen Master & Xen Axis
1 - 120 Call Arrival Key Block Assignment
A6-324000-642-02 - Release 6.0
May 2003
Related Programming
M.B. Number Memory Block Name
Refer to Chapter 2 Guide to Feature Programming.
N
1. The Xen Master (V1.XX, V2.XX and V3.XX) system allows a maximum of 120 ports to be shared by station ports
(ESI, SLI, VMS) and Call Arrival Keys. If 32 station ports are being used, 88 remain for use as Call Arrival Keys.
2. The Xen Axis (V1.XX and V2.XX) system allows a maximum of 32 ports to be shared by station ports (ESI, SLI, VMS)
and Call Arrival Keys. If 24 station ports are being used, 8 remain for use as Call Arrival Keys.
3. The Xen Axis V3.XX system allows a maximum of 32 physical ports to be shared by station ports (ESI, SLI, VMS) and
Call Arrival keys, but has 16 extra Call Arrival keys which expand the maximum CAR key assignment to 40. If 32 ports
are being used, 16 Call Arrival keys remain to be used.
Maximum
Ports
Physical
Maximum
Physical Ports
+ CAR Ports
Maximum CAR
Ports Only
MASTER
V1.XX ~ V3.XX
120 120 112
AXIS
V1.XX + V2.XX
32 32 24
AXIS
V3.XX or Higher
32 48 40
