1 - 408 Telephone Type Assignment
NEC Business Solutions Ltd Xen Master & Xen Axis
A6-324000-642-02 - Release 6.0
May 2003
7-2
System Mode
7
Telephone
2
Data No.
—
PC Programming
a
+BS
Telephone Type Assignment
General Description
Use this Memory Block to specify the type of device that is connected to an ESI port.
Display
Settings
LK 1 LK 2 LK 3 LK 4
The shaded area indicates the default setting.
Non Telephone
DSS Con-
sole
SLT
Adapter
LK 5 LK 6 LK 7 LK 8
Digital
Voice Mail
Programming Procedures
1 Go off-line.
2 Press LK7 + LK2
to access the Memory Block.
3 To change data, press the corresponding CO/PBX line key.
Note: Use the following to enter data:
R: Next Tel Port No.
4 Press
Nto write the data.
5 Press
Pto go back on-line.
Related Programming
M.B. Number Memory Block Name
Refer to Chapter 2 Guide to Feature Programming.
N
1. Only Multiline Terminals can be assigned to ports 01 and 02.
2. A maximum of four Attendant Add-On Consoles can be installed in the system.
3. A maximum of eight SLT(1)-U13 ADP adapters can be installed in the system.
4. A maximum of eight Digital Voice Mail ports are available.
5. When assigning SLT adapters or Digital Voice Mail ports, Memory Block 4-10 Station Number Assignment must be
reassigned also.
6. If more than one DSS console is assigned, make sure that the order of assignment is as follows:
 DSS1 must always be a lower port than DSS2
 DSS2 must be a lower port than DSS 3
 DSS3 must be a lower port than DSS 4
0 1 : T E L
T I M E D I S P L A Y
ESI
Port No.
(01~96)
Setting Data
To Next Page
