NEC Xen Master Programming Manual

1 - 356 Extension Line Key Ring Assignment (Day Mode)
NEC Business Solutions Ltd Xen Master & Xen Axis
A6-324000-642-02 - Release 6.0 May 2003
The shaded area is the default setting.
4-37
System Mode
4
Submode
—
Data No.
37
PC Programming
a
+BTM
Extension Line Key Ring
Assignment (Day Mode)
General Description
Use this Memory Block to specify the ringing assignment on incoming calls to a Secondary
Incoming Extension (SIE) or a Call Arrival key.
Display
Settings
Page 1 (Line Keys 01~08)
LK 1 LK 2 LK 3 LK 4
There is no default setting.
1234
LK 5 LK 6 LK 7 LK 8
5678
Page 2 (Line Keys 09~16)
LK 1 LK 2 LK 3 LK 4
9101112
LK 5 LK 6 LK 7 LK 8
13 14 15 16
Page 3 (Line Keys 17~24)
LK 1 LK 2 LK 3 LK 4
17 18 19 20
LK 5 LK 6 LK 7 LK 8
21 22 23 24
Programming Procedures
1 Go off-line.
2 Press LK4 +CG to access the Memory Block.
3 Use the dial pad to select option.
The LED indication changes to indicate data each time a CO/PBX line key is
pressed.
Note: Use the following to enter data:
S go to next page
T go to previous page
Rto select next Tel Port No.
Default Values
All Telephones: No Ring
4 Press
Nto write the data.
5 Press
Pto go back on-line.
0 1 / 3 7 : E X T D A Y | 0 1
T I M E D I S P L A Y
Data
No.
T
e
l
P
or
t
N
o.
(01~99)
A0~C0
Title
Page
CO/PBX
Line Key LED
Off Green Red
Data
No ring
Immediat
e Ring
Delayed
Ring
