NEC Xen Master Programming Manual

CO/PBX Ring Assignment (Day Mode) 1 - 321
Programming Manual May 2003
A6-324000-642-02 - Release 6.0 May 2003
4-01
System Mode
4
Submode
—
Data No.
01
PC Programming
a
+BTT
CO/PBX Ring Assignment
(Day Mode)
General Description
Use this Memory Block to assign incoming CO/PBX calls to ring on Multiline Terminals in
the Day Mode.
Display
Settings
Page 1 (Ports 01~08)
LK 1 LK 2 LK 3 LK 4
The shaded area indicates the default setting.
01 02 03 04
LK 5 LK 6 LK 7 LK 8
05 06 07 08
Page 2 (Ports 09~16)
LK 1LK 2LK 3LK 4
09 10 11 12
LK 5 LK 6 LK 7 LK 8
13 14 15 16
Page 3 (Ports17~24)
LK 1LK 2LK 3LK 4
17 18 19 20
LK 5 LK 6 LK 7 LK 8
21 22 23 24
Page 4 (Ports 25~32)
LK 1LK 2LK 3LK 4
25 26 27 28
LK 5 LK 6 LK 7 LK 8
29 30 31 32
Page 5 (Ports 33~40)
LK 1LK 2LK 3LK 4
33 34 35 36
LK 5 LK 6 LK 7 LK 8
37 38 39 40
Page 6 (Ports 41~48)
LK 1LK 2LK 3LK 4
41 42 43 44
LK 5 LK 6 LK 7 LK 8
45 46 47 48
0 1 / 0 1 : R N G D Y | 0 1
T I M E D I S P L A Y
Data
No.
Page
(01~08)
Title
Tel Port
No.
(01~99)
A0~C0
