NEC Xen Master Programming Manual

Attendant Add-On Console to Telephone Port Assignment 1 - 175
Programming Manual May 2003
A6-324000-642-02 - Release 6.0 May 2003
1-6-01
System Mode
1
Submode
6
Data No.
01
PC Programming
a
+BTD
Attendant Add-On Console to
Telephone Port Assignment
General Description
Use this Memory Block to assign an Attendant Add-On Console to a telephone port
number.
Display
Programming Procedures
1 Go off-line.
2 Press LK1 +
LK6.
3 Use
Jto move cursor to the second Data No. position and press Ato access the Memory Block.
4 Use the dial pad to enter the data.
Note: Use the following to enter data:
J to move the cursor left
L to move the cursor right
K~Ito enter numeric data
Default Values
5 Press
Nto write the data.
6 Change the data using the dial pad.
7 Press
Nto write the data.
8 Press
Pto go back on-line.
Related Programming
M.B. Number Memory Block Name
7-2
Telephone Type Assignment
N
1. The telephone with an Attendant Add-On Console connected must be specified by port number.
2. A maximum of four Attendant Add-On Consoles can be connected to a system.
3. A maximum of four Attendant Add-On Consoles can be connected to one telephone.
0 1 : D S S 1 = P 0 1
T I M E D I S P L A Y
Data
No.
Title
Setting
Data
DSS No.
1~4
DSS Tel Port No.
1› 01
2› 02
3› 01
4› 02
