1 - 386 Internal Zone Paging Selection
NEC Business Solutions Ltd Xen Master & Xen Axis
A6-324000-642-02 - Release 6.0
May 2003
4-93
System Mode
4
Submode
—
Data No.
93
PC Programming
a
+BTM
Internal Zone Paging Selection
General Description
Use this Memory Block to place stations in Internal page zones.
Display
Settings
LK 1 LK 2 LK 3 LK 4
The shaded area indicates the default setting.
No Zone A Zone B Zone C
LK 5 LK 6 LK 7 LK 8
Programming Procedures
1 Go off-line.
2 Press LK4 +
IC to access the Memory Block.
3 Press the corresponding CO/PBX line key to change data option.
Note: Use the following to change option:
R select next Tel Port No.
4 Press
Nto write the data.
5 Press
Pto go back on-line.
Related Programming
No related programming is necessary for this Memory Block.
N
1. Specify one zone:
All Internal Zones: Paged by dialling 51
Zone A: Paged by dialling 52
Zone B: Paged by dialling 53
Zone C: Paged by dialling 54.
2. Telephones can be assigned to NO Zone. All Internal Zones page the telephone unless No Page Receive is assigned
in Memory Block 4-31 Receiving Internal/All Call Page Selection.
3. All Internal Zones pages all of the idle Multiline Terminals.
4. Telephone ports A0~C0 are ports 100~120.
0 1 / 9 3 : Z O N E N O
T I M E D I S P L A Y
Data
No.
Tel Port No.
(01~99)
A0~C0
Title
Setting
Data
To Next Page
