NEC Xen Master - 1-1-53 Tie Line Delay Ring Pattern Selection

Tie Line Delay Ring Pattern Selection 1 - 83
Programming Manual May 2003
A6-324000-642-02 - Release 6.0 May 2003
1-1-53
System Mode
1
Submode
1
Data No.
53
PC Programming
a
+ALN
Tie Line Delay Ring Pattern
Selection
General Description
Use this Memory Block to select a ringing pattern for incoming calls on a Tie line after the
timeout set in Memory Block 1-1-07.
Display
Settings
(Page 1)
LK 1 LK 2
LK 3 LK 4
Ring Pattern
A
Ring Pattern
B
Ring Pattern
C
Ring Pattern
D
LK 5 LK 6 LK 7 LK 8
Ring Pattern
E
Ring Pattern
F
Ring Pattern
G
Ring Pattern
H
(Page 2)
The shaded area indicates the default setting.
LK 9 LK 10 LK 11 LK 12
No Ring
LK 13 LK 14 LK 15 LK 16
Programming Procedures
1 Go off-line.
2 Press LK1 + LK1 +
EC to access the Memory Block.
3 Press the corresponding CO/PBX line key to change the data option.
Note: Use the following to enter data:
Sto access the next page
Tto access the previous page
4 Press data.
5 Press
Pto go back on-line.
Related Programming
M.B. Number Memory Block Name
1-1-07
Tie Line Delay Ringing Timer Selection
1-1-34
Tie Line First Ring Pattern Selection
4-01
CO/PBX Ring Assignment (Day Mode)
4-02
CO/PBX Ring Assignment (Night Mode)
5 3 : T L I P T N C | 1
T I M E D I S P L A Y
Data
No.
Title
Setting
Data
Page
No.
