NEC Xen Master - 3-29 Trunk Internal Transmit Pad Selection

1 - 288 Trunk Internal Transmit Pad Selection
NEC Business Solutions Ltd Xen Master & Xen Axis
A6-324000-642-02 - Release 6.0 May 2003
3-29
System Mode
3
Submode
—
Data No.
29
PC Programming
a
+BCT
Trunk Internal Transmit Pad
Selection
General Description
This Memory Block specifies a volume level for calls originated from the extensions of a
local system to a distant system.
Display
Settings
(Page 1)
LK 1 LK 2 LK 3
LK 4
The shaded area indicates the default setting.
2 dB 4 dB 6 dB 8 dB
LK 5 LK 6 LK 7 LK 8
12 dB 16 dB 3 dB -3 dB
(Page 2)
LK 1 LK 2 LK 3 LK 4
0 dB
LK 5 LK 6 LK 7 LK 8
Programming Procedures
1 Go off-line.
2 Press LK3 +
N + BI to access the Memory Block.
3 Press the corresponding CO/PBX line key to change the data option.
Note: Use the following to enter data:
S to go to the next page
T to go to the previous page
R to go to the next CO/PBX Line No.
4 Press
Nto write the data.
5 PressPto go back on-line.
Related Programming
No related programming is necessary for this Memory Block.
0 1 / 2 9 : P A D I T 8 | 1
T I M E D I S P L A Y
Page
No.
Setting
Data
Title
Data
No.
CO/PBX
No.
(01~64)
