Programming Manual May 2003
Trunk Internal Transmit Pad Selection 1 - 289
A6-324000-642-02 - Release 6.0
May 2003
N
1. The Xen system divides the connections into the following patterns:
2. The Memory Block applies to Tie lines, T1, DID, and Basic Rate Interface (BRI) trunks.
(Specify the sending and receiving levels of each pattern for each of the trunks.)
Pattern A (Intercom Mode)
Sending level
Receiving level
Pattern B (Tandem Mode)
Sending level
Receiving level
Connections established between the intercom stations of the local
system and trunks.
(To be specified in this Memory Block.)
Connections established between two systems, with the local system
as a tandem system.
