NEC Business Solutions Ltd Xen Master & Xen Axis
1 - 404 Card Interface Slot Assignment
A6-324000-642-02 - Release 6.0
May 2003
3 Use the Line key to enter data.The following is the operation data:
Note: Use the following to enter data:
J to move the cursor left
L to move the cursor right
K~I to enter numeric data
S to go to the next page
T to go to the previous page
Enter Slot No. A using dial pad (9)
Enter Slot No. B using dial pad (0)
4 To assign upper Slot No. for PRI(1)-13, press
Qand enter the first number of the next block of 4 ports.
5 Press
Nto write the data.
6 Press
Pto go back on-line.
Programming Procedures (Continued)
Page 1
Line Key Setting Data LCD Indication
1NON
2 COI(4)-U13 (NZ U19) COI 4
3 COI(8)-U13 (NZ U19) COI 8
4NON
5 COID(4)-U13 (NZ U19) COID 4
6 COID(8)-U13 (NZ U19) COID 8
7 TLI(2)-U13 TLI
8 DID(4)-U13 (NZ N/A) DID
Page 2
Line Key Setting Data LCD Indication
1 ESI(8)-U13 ESI
2NON
3
SLI(8)-U13
CNF(8)-U13
(Note 18)
SLI
4 OPX(2)UB OPX *
5 VDH2(8)-U13 VDH
6 DPH(4)-U13 DPH
7 PBR( )-U13 PBR
8ECR-U13 ECR
Page 3
Line Key Setting Data LCD Indication
1 VRS(4)-U13 VRS
2
3 VMS(2/4)-U13 VMS 4
4 VMS(8)-U13 VMS 8
5 BRT(4)-U13 BRT
6NON
7 PRI(1)-U13 PRT
8 MIFM-U13 MIFM
Page 4
Line Key Setting Data LCD Indication
1MIFA-U13 MIFA
2NON
3BSC-U13
4 BIU(2)-U13
5NON
6NON
7 BSU(2)-U13 BSU2*
8 SLI(4)-U13 SLI4*
* Software Version 2.x or higher
