NEC Business Solutions Ltd Xen Master & Xen Axis
1 - 254 Trunk to Tenant Assignment
A6-324000-642-02 - Release 6.0
May 2003
Programming Procedures
1 Go off-line.
2 Press LK2 +
KAto access the Memory Block.
3 Press the corresponding CO/PBX line key to change the data option.
Note: Use the following to enter data:
J to move the cursor left
L to move the cursor right
K~I to enter numeric data
Rto go to the next Tenant No.
S to go to the next page
T to go to the previous page
Default Values
4 Press
Nto write the data.
5 Press
Pto go back on-line.
Related Programming
M.B. Number Memory Block Name
2-05
Line Key Selection
4-09
Telephone to Tenant Assignment
N
If data is changed while the system is busy, DATA ENTRY is displayed at the programming station until the system
becomes idle.
CO/PBX
Line LED
Off Off
Data
No
(Not Assigned)
Yes
(Assigned)
Tenant
00
Tenant
01~47
CO/PBX lines 01~64
assigned (YES)
Not
assigned
There is no default setting.
To Next Page
