Programming Manual May 2003
Trunk External Receive Pad Selection 1 - 295
A6-324000-642-02 - Release 6.0
May 2003
N
1. The Xen system divides the connections into the following patterns:
2. The Memory Block applies to Tie lines, T1, DID, and ISDN trunks.
(Specify the sending and receiving levels of each pattern for each of the trunks.)
Pattern A (Intercom Mode)
Sending level
Receiving level
Pattern B (Tandem Mode)
Sending level
Receiving level
Connections established between the intercom stations of the local
system and trunks.
Connections established between two systems, with the local system
as a tandem system.
(To be specified in this Memory Block.)
