NEC Xen Master Programming Manual

NEC Business Solutions Ltd Xen Master & Xen Axis
1 - 328 Automatic Outgoing CO/PBX Line Selection
A6-324000-642-02 - Release 6.0 May 2003
Page 7 (Ports 49~56)
LK 1 LK 2 LK 3 LK 4
49 50 51 52
LK 5 LK 6 LK 7 LK 8
53 54 55 56
Page 8 (Ports57~64)
LK 1 LK 2 LK 3 LK 4
57 58 59 60
LK 5 LK 6 LK 7 LK 8
61 62 63 64
Programming Procedures
1 Go off-line.
2 Press LK4 +
KE to access the Memory Block.
3 Press the CO/PBX Line key corresponding to each CO/PBX number.
The LED indication changes to indicate data each time a CO/PBX line key is
pressed.
Note: Use the following to enter data:
J to move the cursor left
L to move the cursor right
Rto move to the next Tel No.
S to move to the next page
T to move to the previous page
Default Values
Tel Port (01-CO) = All trunks (01~64)
set to “YES”
4 After entering all data for all pages, press
Nto write the data.
5 Press
Pto go back on-line.
Related Programming
M.B. Number Memory Block Name
1-1-46
Access Code (1-Digit) Assignment
1-1-47
Access Code (2-Digit) Assignment
1-1-48
Access Code (3-Digit) Assignment
N
1. Telephone ports A0~C0 are ports 100~120.
2. Selection is made on a port by port, line by line basis.
Settings
CO/PBX
Line Key LED
Off Green
Data
NO
Selection
YES
Selection
