NEC Business Solutions Ltd Xen Master & Xen Axis
1 - 342 Trunk Outgoing Restriction
A6-324000-642-02 - Release 6.0
May 2003
Page 7 (Ports 49~56)
There is no default setting.
LK 1LK 2LK 3LK 4
49 50 51 52
LK 5 LK 6 LK 7 LK 8
53 54 55 56
Page 8 (Ports 57~64)
LK 1LK 2LK 3LK 4
57 58 59 60
LK 5 LK 6 LK 7 LK 8
61 62 63 64
29 30 31 32
Programming Procedures
1 Go off-line.
2 Press LK4 +
AI to access the Memory Block.
3 Press the CO/PBX line key corresponding to each CO/PBX line.
The LED indication changes to indicate data each time a CO/PBX line key is pressed.
Note: Use the following to enter data:
J to move the cursor left
L to move the cursor right
K~I to enter numeric data
U to clear all data when cursor is at setting data position
Rto go to next Tel Port No.
Default Values
Off, Not Restricted.
4 After entering all data for all pages, Press
Nto write the data.
5 Press
Pto go back on-line.
Related Programming
No related programming is necessary for this Memory Block.
N
1. A restricted CO/PBX line allows the station user to answer an incoming call or access a held call, but does not
allow a user to originate a CO/PBX call.
2. If restricted is specified in this section, the data in Memory Blocks 4-07 Code Restriction Class Assignment
(Day Mode) and Memory Block 4-08 Code Restriction Class Assignment (Night Mode) is treated as invalid
even if specified.
3. Telephone ports A0~C0 are ports 100~120.
Settings
CO/PBX
Line Key LED
Off On
Data
Not Restricted Restricted
The shaded area indicates the default setting.
To Next Page
