NEC Xen Master Programming Manual

NEC Business Solutions Ltd Xen Master & Xen Axis
1 - 406 Card Interface Slot Assignment
A6-324000-642-02 - Release 6.0 May 2003
*1 C :Port Number of CO/PBX Line
T :Telephone Port Number (smallest number is displayed)
V :Voice Recording Service Package
– :No Display
*2 O :When the ETU is assigned to a lower slot, it can be assigned also to an upper slot in the same manner
X :When the ETU is assigned to a lower slot, it cannot be assigned to another unit in an upper slot.
*3 O :Enabled
Space :Disabled
1:E64
2:B64
Table 1-4 Card Interface Slot Assignment - Xen Master
XEN Master
KTU Unit
Port
(*1)
Upper
(*2)
Slot (*3)
ISA12345678
ESI(8)-U13 T X OOOOOOOO
SLI(8)-U13/CNF(8)-U13 T X OOOOOOOO
COI(8)-U13 (NZ - U19) C X OOOOOOOO
COI(4)-U13 (NZ - U19) C O OOOOOOOO
DID(4)-U13 (NZ - N/A) C O OOOOOOOO
TLI(2)-U13 C O OOOOOOOO
VDH2(8)-U13 T OOOOOOOO
PBR( )-U13 – X OOOOOOOO
DPH(4)-U13 – OOOOOOOO
ECR-U13 – X OOOOOOOO
VMS(2/4)-U13 T OOOOOOOO
VMS(8)-U13 T OOOOOOOO
VRS(4)-U13 V X OOOOOOOO
COID(4/8)-U13
(NZ - U19) C X OOOO
BRT(4)-U13 C OOOO
PRT(1)-U13 C O
1
O
2
BSC-U13 – O
BIU(2)-U13 – OOO
MIFA-U13 – X OOO
MIFM-U13 – X OOO
BSU(2)-U13 – OOOOOOOO
OPX(2)-U13 – OOOOOOOO
SLI(4)-U13 T X OOOOOOOO
FMS(2/4)-U13 T OOOOOOOOO
