8-Digit Matching Tables with Default Values
The following designations are used in this table:
8-Digit Matching Table to Class Assignment (1-1-61)
Class Allow/Deny Selection (1-1-65)
8-Digit Matching Table Class
Allow/Deny
Assignment
8-Digit
Matching
Table to
Class
Assignment
01 02 03 04 05 06 07 08 09 10 11 12 13 14 15 16
Class 02 A D D D Allow
Class 03 A D A D D Allow
Class 04 A D D A D D Allow
Class 05 A A D D Allow
Class 06 A Deny
Class 07 A Deny
Class 08 A Deny
Class 09 A Deny
Class 10 A Deny
Class 11 A Deny
Class 12 A Deny
Class 13 A Deny
Class 14 A Deny
Class 15 A Deny
Note: A = Allow
D = Deny
Blank = Not used
