Date Code 20170927 Instruction Manual SEL-751 Relay
Section 3
PC Software
Overview
SEL provides many PC software solutions (applications) to support the
SEL-751 Relay and other SEL devices. Table 3.1 lists SEL-751 software
solutions.
This section describes how to get started with the SEL-751 and
ACSELERATOR QuickSet. QuickSet is a powerful setting, event analysis, and
measurement tool that aids in setting, applying, and using the SEL-751.
Table 3.2 shows the suite of QuickSet applications provided for the SEL-751.
Table 3.1 SEL Software Solutions
Part Number Product Name Description
SEL-5010 SEL-5010 Relay Assistant Software Manages a connection directory and settings of
multiple devices.
SEL-5030
ACSELERATOR QuickSet
SEL-5030 Software See Table 3.2.
SEL-5032
ACSELERATOR Architect SEL-5032 Software Configures IEC 61850 communications.
SEL-5036
ACSELERATOR Bay Screen Builder SEL-5036 Software Designs and manages bay screens in conjunction
with SEL-5030 for the SEL-751 with color
touchscreen display.
SEL-5040
ACSELERATOR Report Server SEL-5040 Software Automatically retrieves, files, and summarizes
reports.
SEL-5601
ACSELERATOR Analytic Assistant SEL-5601 Software Converts SEL Compressed ASCII event report files
to oscillography.
SEL-5801 SEL-5801 Cable Selector Software Selects the proper SEL cables for your application.
Ta b le 3 . 2 ACSELERATOR QuickSet SEL-5030 Software (Sheet 1 of 2)
Application Description
Rules-Based Settings Editor Provides online or offline device settings that include interdependency checks. Use this feature to
create and manage settings for multiple devices in a database.
HMI Provides a summary view of device operation. Use this feature to simplify commissioning
testing.
Design Templates
a
Allows you to customize device settings to particular applications and store those settings in
Design Templates. You can lock settings to match your standards or lock and hide settings that
are not used.
Event Analysis Provides oscillography and other event analysis tools.
Bay Control Allows you to design new bay screens and edit existing bay screens by launching
ACSELERATOR
Bay Screen Builder SEL-5036 Software for SEL-751 relays with the color touchscreen display.
Setting Database Management QuickSet uses a database to manage the settings of multiple devices.
