10.9
Date Code 20170927 Instruction Manual SEL-751 Relay
Analyzing Events
Event Reporting
Use the EVE command to retrieve the reports. There are several options to
customize the report format.
Filtered and Unfiltered Event Reports
The SEL-751 samples the power system measurands (ac voltage and ac
current) 32 times per power system cycle. A digital filter extracts the
fundamental frequency component of the measurands. The relay operates on
the filtered values and reports these values in the standard, filtered event
report.
To view the raw inputs to the relay, use the EVE
R command to select the
unfiltered event report. Use the unfiltered event reports to observe power
system conditions:
Power system transients on current and voltage channels
Decaying dc offset during fault conditions on current channels
Raw event reports display one extra cycle of data at the beginning of the
report.
Event Report Column Definitions
Refer to the example event report in Figure 10.3 to view event report columns.
This example event report displays rows of information each 1/4 cycle.
Retrieve this report with the EVE command.
The columns contain ac current, ac voltage, input, output, and protection and
control element information. Use the serial port SUM command (see
SUMMARY Command on page 7.53) to retrieve event summary reports.
Table 10.3 summarizes the event summary report current and voltage
columns. Table 10.4 summarizes the event summary report output, input,
protection, and control element columns.
Table 10.3 Event Report Current and Voltage Columns
Column
Heading
Description
IA
Current measured by channel IA (primary A)
IB
Current measured by channel IB (primary A)
IC
Current measured by channel IC (primary A)
IG
Residual current (IA + IB + IC, primary A)
IN
Current measured by channel IN (primary A)
VAN or VAB
Voltage measured by channel VAN or VAB (primary V)
VBN or VBC
Voltage measured by channel VBN or VBC (primary V)
VCN or VCA
Voltage measured by channel VCN or VCA calculated from VAB and
VBC (primary V)
VS
Voltage measured by channel VS (terminals VS, NS) (primary V)
VDC
Voltage measured by channel VDC (terminals VBAT+, VBAT–)
