F.19
Date Code 20170927 Instruction Manual SEL-751 Relay
IEC 61850 Communications
Logical Nodes
Logical Nodes
The following tables, Table F.20 through Table F.24, show the Logical Nodes
(LN) supported in the SEL-751 and the associated Relay Word bits or
measured quantities. Table F.20 shows the LN associated with protection
elements defined as Logical Device PRO.
Data Objects
Status Information
ColOpn SPS Open command of trip coil M
Measured Values
AbrPrt MV Calculated or measured wear (e.g. of main contact), expressed in % where
0% corresponds to new condition
E
a
Transient data objects—the status of data objects with this designation is momentary and must be logged or reported to provide evidence
of their momentary state.
b
M: Mandatory; O: Optional; C: Conditional; E: Extension
Table F.19 Circuit Breaker Supervision (Per-Phase) Logical Node Class Definition (Sheet 2 of 2)
SCBR Class
Table F.20 Logical Device: PRO (Protection) (Sheet 1 of 13)
Logical Node Attribute Data Source Comment
Functional Constraint = CO
BKR1CSWI1 Pos.Oper.ctlVal CC
a
Breaker close/open command
Functional Constraint = DC
DevIDLPHD1 PhyNam.model PARTNO Part number
Functional Constraint = MX
a
FLTRFLO1 FltZ.instCVal.mag.f FZ Fault impedance magnitude of the most recent fault
FLTRFLO1 FltZ.instCVal.ang.f FZFA Fault impedance angle of the most recent fault
FLTRFLO1 FltDiskm.instMag.f FLOC Fault location of the most recent fault
FLTRFLO1 FltA.phsA.instCVal.mag.f FIA A-phase current of the most recent fault event
FLTRFLO1 FltA.phsB.instCVal.mag.f FIB B-phase current of the most recent fault event
FLTRFLO1 FltA.phsC.instCVal.mag.f FIC C-phase current of the most recent fault event
FLTRFLO1 FltA.neut.instCVal.mag.f FIN Neutral current of the most recent fault event
FLTRFLO1 FltA.res.instCVal.mag.f FIG Residual current of the most recent fault event
Functional Constraint = ST
A55POPF1 Op.general 55A Power factor alarm
A55POPF1 Str.general 55A Power factor alarm
A55POPF1 Str.dirGeneral unknown Direction undefined
ATPTOC20 Op.general 51AT A-phase time-overcurrent element trip
