E.8
SEL-751 Relay Instruction Manual Date Code 20170927
Modbus RTU Communications
Communications Protocol
Table E.14 01h, 05h SEL-751 Output (Sheet 1 of 3)
Coil Address (Decimal) Function Code Supported Coil Description
0 01, 05 Pulse OUT101 1 second
1 01, 05 Pulse OUT102 1 second
2 01, 05 Pulse OUT103 1 second
3 01, 05 Pulse OUT301 1 second
4 01, 05 Pulse OUT302 1 second
5 01, 05 Pulse OUT303 1 second
6 01, 05 Pulse OUT304 1 second
7 01, 05 Pulse OUT305 1 second
8 01, 05 Pulse OUT306 1 second
9 01, 05 Pulse OUT307 1 second
10 01, 05 Pulse OUT308 1 second
11 01, 05 Pulse OUT401 1 second
12 01, 05 Pulse OUT402 1 second
13 01, 05 Pulse OUT403 1 second
14 01, 05 Pulse OUT404 1 second
15 01, 05 Pulse OUT405 1 second
16 01, 05 Pulse OUT406 1 second
17 01, 05 Pulse OUT407 1 second
18 01, 05 Pulse OUT408 1 second
19 01, 05 Pulse OUT501 1 second
20 01, 05 Pulse OUT502 1 second
21 01, 05 Pulse OUT503 1 second
22 01, 05 Pulse OUT504 1 second
23 01, 05 Pulse OUT505 1 second
24 01, 05 Pulse OUT506 1 second
25 01, 05 Pulse OUT507 1 second
26 01, 05 Pulse OUT508 1 second
27 01, 05 RB01
28 01, 05 RB02
29 01, 05 RB03
30 01, 05 RB04
31 01, 05 RB05
32 01, 05 RB06
33 01, 05 RB07
34 01, 05 RB08
35 01, 05 RB09
36 01, 05 RB10
37 01, 05 RB11
