4.208
SEL-751 Relay Instruction Manual Date Code 20170927
Protection and Logic Functions
DNP Map Settings (Set DNP n Command, n = 1, 2, or 3)
HIF Event Report
Settings
Load Profile Settings
Use the LDLIST setting to declare the analog quantities you want included in
the Load Profile Report. Enter as many as 17 analog quantities, separated by
spaces or commas, into LDLIST setting. See Appendix L: Analog Quantities
for a list of the available Analog Quantities. Also set the LDAR to the desired
acquisition rate for the report.
IMPORTANT: All stored load data
are lost when changing the LDLIST.
DNP Map Settings (Set DNP n Command, n = 1, 2, or 3)
Table 4.107 shows the available settings. See Appendix D: DNP3 Communi-
cations for additional details.
Table 4.105 HIF Event Report Settings
Setting Prompt Setting Range
Setting Name :=
Fac to ry Defa ult
HIF EVENT LENGTH 2, 5, 10, 20 min HIFLER := 10
Table 4.106 Load Profile Settings
Setting Prompt Setting Range
Setting Name :=
Fac to ry Defa ult
LDP LIST NA, as many as 17 Analog Quantities LDLIST := NA
LDP ACQ RATE 5, 10, 15, 30, 60 min LDAR := 15
Table 4.107 DNP Map Settings
a
(Sheet 1 of 2)
Setting Prompt Setting Range
Setting Name :=
Fac to ry Default
DNP Binary Input Label Name 10 characters BI_00 := ENABLED
DNP Binary Input Label Name 10 characters BI_01 := TRIP_LED
DNP Binary Input Label Name 10 characters BI_02 := TLED_01
DNP Binary Input Label Name 10 characters BI_03 := TLED_02
·
·
·
DNP Binary Input Label Name 10 characters BI_99 := NA
DNP Binary Output Label Name 10 characters BO_00 := RB01
·
·
·
DNP Binary Output Label Name 10 characters BO_31 := RB32
DNP Analog Input Label Name 24 characters AI_00 := IA_MAG
DNP Analog Input Label Name 24 characters AI_01 := IB_MAG
·
·
·
DNP Analog Input Label Name 24 characters AI_99 := NA
DNP Analog Output Label Name 6 characters AO_00 := NA
