for all conditions listed in the SUM HIF command. When an event report is
triggered for any of these conditions, the SEL-751 asserts Relay Word bit
HIFREC, which stays asserted until the HIF event report has finished
collecting. The relay does not generate additional event reports for triggering
conditions that follow the initial triggering condition and are within the same
report.
The number of event reports the relay shall be able to store depends on the
HIFLER setting at the rate of 1 sample/2 cycles. For example, if the HIFLER
setting is 10 minutes, then the relay should be able to store at least four back-
to-back event reports. Figure 7.20 shows an example of the CEV HIF
command response.
=>>CEV HIF <Enter>
"FID","0143"
"FID=SEL-751-X381-V0-Z007002-D20161207","08B6"
"MONTH","DAY","YEAR","HOUR","MIN","SEC","MSEC","0ACA"
12,19,2016,11,46,46,594,"04A2"
"REC_NUM","NUM_CH_A","NUM_CH_D","SAM/CYC_A","SAM/CYC_D","NUM_OF_CYC","PRIM_VAL","14ED"
1,33,48,0.5000,0.5000,10800,"YES","06AB"
"IARMS(A)","IBRMS(A)","ICRMS(A)","SDIA(A)","SDIB(A)","SDIC(A)","SDIAREF(A)","SDIBREF(A)","SDICREF(A)","dA(A)","dB(A)","dC(A)
","ISMA(A)","ISMB(A)","ISMC(A)","ISMAREF(A)","ISMBREF(A)","ISMCREF(A)","DLT_T1A(A)","DLT_T1B(A)","DLT_T1C(A)","T7CNTA",
"T7CNTB","T7CNTC","T8CNTA","T8CNTB","T8CNTC","SW1AL","SW1AH","SW1BL","SW1BH","SW1CL","SW1CH","TRIG","HIA1_A HIA1_B
HIA1_C HIF1_A HIF1_B HIF1_C NTUNE_A NTUNE_B NTUNE_C 3PH_A 3PH_B 3PH_C DL2CLRA DL2CLRB DL2CLRC ITUNE_A ITUNE_B ITUNE_C
DIA_DIS DIB_DIS DIC_DIS DVA_DIS DVB_DIS DVC_DIS HIA2_A HIA2_B HIA2_C FRZCLRA FRZCLRB FRZCLRC DUPA DUPB DUPC HIF2_A HIF2_B
HIF2_C LRA LRB LRC DDNA DDNB DDNC 3PH_CLR LR3 HIFER HIFMODE 3PH_EVE HIFREC","A55A"
621.0,621.0,621.0,102.7,128.3,115.5,121.9,121.9,121.9,24.9,50.5,51.3,51.3,57.8,51.3,51.3,57.8,57.8,0,0,0,0,0,0,0,0,0,0,0,0,0
,0,0, ,"038000000000","1B6E"
621.0,621.0,621.0,128.3,128.3,109.1,121.9,121.9,121.9,24.9,50.5,51.3,44.9,57.8,64.2,51.3,57.8,57.8,0,0,0,0,0,0,0,0,0,0,0,0,0
,0,0, ,"038000000000","1B7C"
621.0,621.0,621.0,128.3,121.9,141.2,121.9,121.9,121.9,24.9,50.5,51.3,44.9,57.8,51.3,51.3,57.8,57.8,0,0,0,0,0,0,0,0,0,0,0,0,0
,0,0, ,"038000000000","1B75"
621.0,621.0,621.0,128.3,134.8,134.8,121.9,121.9,121.9,24.9,50.5,51.3,51.3,57.8,44.9,51.3,57.8,57.8,0,0,0,0,0,0,0,0,0,0,0,0,0
,0,0, ,"038000000000","1B80"
621.0,621.0,621.0,121.9,134.8,134.8,121.9,121.9,121.9,24.9,50.5,51.3,51.3,70.6,51.3,51.3,57.8,57.8,0,0,0,0,0,0,0,0,0,0,0,0,0
,0,0, ,"038000000000","1B70"
622.0,620.0,621.0,128.3,128.3,134.8,121.9,128.3,128.3,24.9,50.5,51.3,44.9,57.8,57.8,51.3,57.8,57.8,0,0,0,0,0,0,0,0,0,0,0,0,0
,0,0, ,"038000000000","1B8B"
621.0,621.0,621.0,128.3,121.9,128.3,121.9,121.9,128.3,24.9,50.5,51.3,44.9,57.8,57.8,51.3,57.8,57.8,0,0,0,0,0,0,0,0,0,0,0,0,0
,0,0, ,"038000000000","1B87"
621.0,621.0,621.0,128.3,115.5,128.3,121.9,121.9,128.3,24.9,50.5,51.3,51.3,57.8,51.3,51.3,57.8,57.8,0,0,0,0,0,0,0,0,0,0,0,0,0
,0,0, ,"038000000000","1B73"
621.0,621.0,621.0,115.5,128.3,141.2,121.9,121.9,128.3,24.9,50.5,51.3,51.3,57.8,51.3,51.3,57.8,57.8,0,0,0,0,0,0,0,0,0,0,0,0,0
,0,0, ,"038000000000","1B6D"
621.0,621.0,621.0,134.8,128.3,121.9,121.9,121.9,128.3,24.9,50.5,51.3,57.8,57.8,57.8,51.3,57.8,57.8,0,0,0,0,0,0,0,0,0,0,0,0,0
,0,0, ,"038000000000","1B8C"
621.0,621.0,621.0,134.8,115.5,147.6,121.9,121.9,128.3,24.9,50.5,51.3,51.3,64.2,57.8,51.3,57.8,57.8,0,0,0,0,0,0,0,0,0,0,0,0,0
,0,0, ,"038000000000","1B7C"
621.0,621.0,620.0,128.3,109.1,128.3,121.9,121.9,128.3,24.9,50.5,51.3,44.9,77.0,51.3,51.3,57.8,57.8,0,0,0,0,0,0,0,0,0,0,0,0,0
,0,0, ,"038000000000","1B73"
621.0,621.0,621.0,141.2,128.3,134.8,121.9,121.9,128.3,24.9,50.5,51.3,32.1,57.8,51.3,51.3,57.8,57.8,0,0,0,0,0,0,0,0,0,0,0,0,0
,0,0, ,"038000000000","1B6E"
621.0,621.0,621.0,115.5,121.9,102.7,121.9,121.9,128.3,24.9,50.5,51.3,57.8,57.8,57.8,51.3,57.8,57.8,0,0,0,0,0,0,0,0,0,0,0,0,0
,0,0, ,"038000000000","1B84"
621.0,621.0,621.0,109.1,115.5,121.9,121.9,121.9,128.3,24.9,50.5,51.3,64.2,64.2,51.3,51.3,57.8,57.8,0,0,0,0,0,0,0,0,0,0,0,0,0
,0,0, ,"038000000000","1B6A"
621.0,621.0,621.0,121.9,109.1,109.1,121.9,121.9,128.3,24.9,50.5,51.3,44.9,64.2,64.2,51.3,57.8,57.8,0,0,0,0,0,0,0,0,0,0,0,0,0
,0,0, ,"038000000000","1B71"
621.0,621.0,621.0,109.1,121.9,134.8,121.9,121.9,128.3,24.9,50.5,51.3,32.1,70.6,51.3,51.3,57.8,57.8,0,0,0,0,0,0,0,0,0,0,0,0,0
,0,0, ,"038000000000","1B69"
621.0,621.0,621.0,96.3,121.9,109.1,121.9,121.9,121.9,24.9,50.5,51.3,44.9,64.2,57.8,51.3,57.8,57.8,0,0,0,0,0,0,0,0,0,0,0,0,0,
0,0, ,"038000000000","1B4F"
621.0,621.0,621.0,141.2,128.3,128.3,121.9,121.9,121.9,24.9,50.5,51.3,44.9,70.6,51.3,51.3,57.8,57.8,0,0,0,0,0,0,0,0,0,0,0,0,0
,0,0, ,"038000000000","1B6F"
621.0,621.0,621.0,115.5,121.9,115.5,121.9,121.9,121.9,24.9,50.5,51.3,38.5,51.3,44.9,51.3,57.8,57.8,0,0,0,0,0,0,0,0,0,0,0,0,0
,0,0, ,"038000000000","1B73"
621.0,621.0,621.0,109.1,121.9,128.3,121.9,121.9,121.9,24.9,50.5,51.3,44.9,57.8,51.3,51.3,57.8,57.8,0,0,0,0,0,0,0,0,0,0,0,0,0
,0,0, ,"038000000000","1B78"
621.0,621.0,621.0,141.2,121.9,134.8,121.9,121.9,128.3,24.9,50.5,51.3,44.9,70.6,64.2,51.3,57.8,57.8,0,0,0,0,0,0,0,0,0,0,0,0,0
,0,0, ,"038000000000","1B74"
621.0,621.0,621.0,134.8,128.3,121.9,121.9,121.9,128.3,24.9,50.5,51.3,38.5,64.2,57.8,51.3,57.8,57.8,0,0,0,0,0,0,0,0,0,0,0,0,0
,0,0, ,"038000000000","1B80"
621.0,621.0,621.0,128.3,134.8,121.9,121.9,121.9,128.3,24.9,50.5,51.3,51.3,51.3,57.8,51.3,57.8,57.8,0,0,0,0,0,0,0,0,0,0,0,0,0
,0,0, ,"038000000000","1B76"
621.0,621.0,621.0,115.5,102.7,128.3,121.9,121.9,128.3,24.9,50.5,51.3,51.3,57.8,57.8,51.3,57.8,57.8,0,0,0,0,0,0,0,0,0,0,0,0,0
,0,0, ,"038000000000","1B7A"
Figure 7.20 CEV HIF Command Response
