IEC 61850 Communications
IEC 61850 Configuration
Incoming GOOSE messages are processed within the following constraints:
➤ You can configure the SEL-751 to subscribe to as many as 64
incoming GOOSE messages.
The SEL-751 recognizes incoming GOOSE messages as valid
based on the following content. Any GOOSE message that fails
these checks is rejected.
➢ Source broadcast MAC address
➢ Dataset Reference
➢ Application ID
➢ GOOSE Control Reference
➤ Rejection of all DA contained in an incoming GOOSE, based
on the accumulation of the following error indications created
by inspection of the received GOOSE:
➢ Configuration Mismatch: the configuration number of
the incoming GOOSE changes.
➢ Needs Commissioning: this Boolean parameter of the
incoming GOOSE is true.
➢ Test Mode: this Boolean parameter of the incoming
GOOSE is true.
➢ Decode Error: the format of the incoming GOOSE is
not as configured.
➤ The SEL-751 discards incoming GOOSE under the following
conditions:
➢ after a permanent (latching) self-test failure
➢ when the relay is disabled
➢ when EGSE is set to No
Link-layered priority tagging and virtual LAN is supported as described in
Annex C of IEC 61850-8-1:2004(E).
IEC 61850 Configuration
Settings
Table F.6 lists IEC 61850 settings. IEC 61850 settings are only available if
your device includes the optional IEC 61850 protocol. Configure all other IEC
61850 settings, including subscriptions to incoming GOOSE messages, with
Architect.
Table F.6 IEC 61850 Settings
Label Description Range Default
E61850 Enables IEC 61850 protocol Y, N N
EGSE
a
a
Settings EGSE and EMMSFS are hidden when E61850 is set to N.
Enables IEC 61850 GSE Y
b
, N
b
Requires that E61850 be set to Y.
N
EMMSFS
a
Enables MMS file services Y
b
, N N
