3.6
SEL-751 Relay Instruction Manual Date Code 20170927
PC Software
Settings
To copy an existing database of devices to a new database:
Step 1. Click File > Database Manager, and select the Copy/Move
Settings Between Databases tab in the Database Manager
dialog box.
QuickSet opens the last active database and assigns it as
Database A.
Step 2. Click the Open B button; QuickSet prompts you for a file
location.
Step 3. Type a new database name, click the Open button, and click
Yes ; the program creates a new empty database. Load devices
into the new database as in Copy/Move Settings Between
Databases on page 3.5.
Settings
ACSELERATOR QuickSet offers the capability of creating settings for one or
more SEL-751 Relays. Store existing relay settings downloaded from
SEL-751 Relays with QuickSet, creating a library of relay settings, then
modify and upload these settings from the settings library to an SEL-751.
QuickSet makes setting the relay easy and efficient. However, you do not have
to use QuickSet to configure the SEL-751; you can use an ASCII terminal or a
computer running terminal emulation software. QuickSet provides the
advantages of rules-based settings checks, SEL
OGIC control equation
Expression Builder, operator control and metering HMI, event analysis, and
help.
Settings Editor
The Settings Editor shows the relay settings in easy-to-understand categories.
The SEL-751 settings structure makes setting the relay easy and efficient.
Settings are grouped logically, and relay elements that are not used in the
selected protection scheme are not accessible. For example, if there is only
one analog card installed in the relay, you can access settings for this one card
only. Settings for the other slots are dimmed (grayed) in the QuickSet menus.
QuickSet shows all of the settings categories in the settings tree view. The
settings tree view remains constant whether settings categories are enabled or
disabled. However, any disabled settings are dimmed when accessed by
clicking an item in the tree view.
Settings Menu
QuickSet uses a database to store and manage SEL relay settings. Each unique
relay has its own record of settings. Use the File menu to Open an existing
record, create and open a New record, or Read relay settings from a connected
SEL-751 and then create and open a new record. Use Tools menu to Convert
and open an existing record. The record is opened in the Setting Editor as a
Setting Form (template) or in Editor Mode.
