6.2
SEL-751 Relay Instruction Manual Date Code 20170927
Settings
View/Change Settings With the Two-Line Front Panel
Touchscreen settings are only available through QuickSet for models with the
color touchscreen display. These settings are not available via ASCII terminal,
unlike the other relay settings. Refer to Section 9: Bay Control for detailed
information on individual settings.
View/Change Settings With the Two-Line Front Panel
You can use the pushbuttons on the front panel to view/change settings.
Section 8: Front-Panel Operations presents the operating details of the front
panel.
Enter the front-panel menu by pushing the ESC pushbutton. The following
message displays:
Scroll down the menu by using the Down Arrow pushbutton until the display
shows the following message:
The cursor (underline) should be on the Set/Show command. Enter the Set/
Show command by pushing the ENT pushbutton. The display shows the
following message:
Enter the underlined
RELAY message with the ENT pushbutton, and the relay
presents you with the
RELAY settings as listed in the SEL-751 Settings Sheets.
Use the Up Arrow, Down Arrow, Left Arrow, and Right Arrow pushbuttons to scroll
through the relay settings. View and change the settings according to your
needs by selecting and editing them. After viewing or changing the
RELAY
settings, press the ESC pushbutton until the following message appears:
Select and enter the appropriate command by pushing the ENT pushbutton.
Select
Yes to save the settings changes and No to discard the changes.
Figure 6.1 shows a front-panel menu navigation example for the relay to enter
the
PHASE PT RATIO, PTR setting.
MAIN
Meter
Control
Set/Show
SET/SHOW
Global
Save Changes?
Yes No
NOTE: Each SEL-751 is shipped with
default factory settings. Calculate the
settings for your application to ensure
secure and dependable protection.
Document the settings on the SEL-751
Settings Sheets at the end of this
section before entering new settings
in the relay.
