Analyzing Events
Event Reporting
.HDR File
The .HDR file contains the event summary and relay settings information that
appears in the event report for the data capture. The settings portion is in a
comma-delimited format as illustrated in Figure 10.9.
FID,"SEL-751-X311-V0-Z006002-D20151119"
Event_Report_Type,"UVR"
Serial_Number,"1112345678"
[SUMMARY]
Time_Source,"External"
Event_Logs,"7"
Event_Number,"10004"
Event_Date,"02/11/2015"
Event_Time,"17:44:49.173300"
Event,"Trip*"
Freq,"59.99"
Targets,"11000000"
Fault_IA_Mag(A),"5000.0625"
Fault_IB_Mag(A),"5038.9111"
Fault_IC_Mag(A),"4965.0024"
Fault_IN_Mag(A),"7.0711"
Fault_IG_Mag(A),"150.0000"
Fault_VAB_Mag(V),"669174.4375"
Fault_VBC_Mag(V),"669364.0625"
Fault_VCA_Mag(V),"1164585.8750"
[Fault_Location]
Location,"$$$$$$$$"
[LGEACY_HDR]
SEL-751 Date: 11/02/2015 Time: 17:44:49.173
FEEDER RELAY Time Source: External
Serial No = 1112345678
FID=SEL-751-X308P-V0-Z006002-D20151111 CID=0000
EVENT LOGS = 7
REF_NUM = 10004
Event: Trip*
Location: $$$$$$$$
Freq: 59.99
Targets: 11000000
Current Mag
IA (A) :5000.0625
IB (A) :5038.9111
IC (A) :4965.0024
IN (A) :7.0711
IG (A) :150.0000
Voltage Mag
VAB (V) :669174.4375
VBC (V) :669364.0625
VCA (V) :1164585.8750
Event Summary Information
PHROT := ABC FNOM := 60 DATE_F := MDY
FAULT := 50G1P OR 50N1P OR 51P1P OR 51QP OR 50Q1P OR TRIP
EMP := N TGR := 3
SS1 := 1
SS2 := 0
SS3 := 0
SS4 := 0
EPMU := N
IRIGC := NONE UTC_OFF := 0.00 DST_BEGM:= OFF
52ABF := N 50BFP := 0.10 BFD := 0.50 ATD := OFF
BFI := R_TRIG TRIP
AO301AQ :=OFF
IN101D := 10 IN102D := 10
IN301D := 10 IN302D := 10 IN303D := 10
EBMON := Y COSP1 := 10000 COSP2 := 150 COSP3 := 12
KASP1 := 1.20 KASP2 := 8.00 KASP3 := 20.00 BKMON := TRIP
Relay Settings
RSTTRGT := 0
RSTENRGY:= 0
RSTMXMN := 0
RSTDEM := 0
RSTPKDEM:= 0
DSABLSET:= 0
TIME_SRC:= IRIG1 TIME_SRC:= IRIG1
Relay Settings
Figure 10.9 Sample COMTRADE .HDR Header File
