8.11
Date Code 20170927 Instruction Manual SEL-751 Relay
Front-Panel Operations
Two-Line Display Front Panel
Set/Show Menu. Select the Set/Show menu item on the MAIN menu. Use the
Set/Show menu to view or modify the settings (Global, Group, and Port),
Active Group, Date, and Time. Note that modifying the settings requires
Level 2 access.
Figure 8.21 MAIN Menu and SET/SHOW Submenu
Each settings class (Global, Group, and Port) includes headings that create
subgroups of associated settings as shown in the following illustration. Select
the heading that contains the setting of interest, and then navigate to the
particular setting. View or edit the setting by pressing the ENT pushbutton. For
text settings, use the four navigation pushbuttons to scroll through the
available alphanumeric and special character settings matrix. For numeric
settings, use the Left Arrow and Right Arrow pushbuttons to select the digit to
change and the Up Arrow and Down Arrow pushbuttons to change the value.
Press the ENT pushbutton to enter the new setting.
You can also make settings changes by using
ACSELERATOR QuickSet
SEL-5030 Software or ASCII SET commands via a communications port.
SET/SHOW
Global
Group
Port
Active Group
Date
Time
Password
(Set/Show Selected)
MAIN
Meter
Events
Targets
Control
Set/Show
Status
Breaker
Quit
