Synchrophasors
Settings for Synchrophasors
Settings for Synchrophasors
The phasor measurement unit (PMU) settings are listed in Table I .1. Modify
these settings when you want to use the C37.118 synchrophasor protocol.
You must set Global enable setting EPMU to Y before the remaining SEL-751
synchrophasor settings are available. No synchrophasor data collection can
take place when EPMU := N.
You must make the serial port settings in Table I.5 or Ethernet port settings in
Table I.6 to transmit data with a synchrophasor protocol. It is possible to set
EPMU := Y without using any ports for synchrophasor protocols. For
example, the port MET PM ASCII command can still be used.
Certain settings in Table I.1 are hidden, depending on the status of other
settings. For example, if PHDATAI := NA, the ICOMP setting is hidden to
Table I.1 PMU Settings in the SEL-751 for C37.118 Protocol in Global Settings
Setting Description Default
EPMU Enable Synchronized Phasor Measurement (Y, N) N
a
a
Set EPMU := Y to access the remaining settings.
MRATE Messages per Second
(1, 2, 5, 10, 25, or 50 when NFREQ := 50)
(1, 2, 4, 5, 10, 12, 15, 20, 30, or 60 when
NFREQ := 60)
10
PMAPP PMU Application (Fast := Fast Response,
Narrow := Narrow Bandwidth)
NARROW
PHCOMP Frequency-Based Phasor Compensation (Y, N) Y
PMSTN Station Name (16 characters) SEL-751 FEEDER1
PMID PMU Hardware ID (1–65534) 1
PHDATAV Phasor Data Set, Voltages (V1, ALL, NA) V1
VCOMP Voltage Angle Comp Factor
(–179.99 to 180.00 deg)
0.00
VSCOMP VS Voltage Angle Comp Factor
(–179.99 to 180.00 deg)
0.00
PHDATAI Phasor Data Set, Currents (I1, ALL, NA) I1
ICOMP Current Angle Comp Factor
(–179.99 to 180.00 deg)
0.00
NUMANA Number of Analog Values (0–4) 0
NUMDSW Number of 16-bit Digital Status Words (0, 1) 0
TREA1 Trigger Reason Bit 1 (SEL
OGIC)TRIP OR ER
TREA2 Trigger Reason Bit 2 (SEL
OGIC) 81D1T OR 81D2T OR
81D3T OR 81D4T
TREA3 Trigger Reason Bit 3 (SEL
OGIC) 59P1T OR 59P2T
b
b
For the SEL-751 model with the currents only option, the default setting is NA.
TREA4 Trigger Reason Bit 4 (SELOGIC) 27P1T OR 27P2T
b
PMTRIG Trigger (SELOGIC) TREA1 OR TREA2 OR
TREA3 OR TREA4
IRIGC IRIG-B Control Bits Definition (NONE, C37.118) NONE
