1.8

SEL-751 Relay Instruction Manual Date Code 20170927

Introduction and Specifications

Applications

Figure 1.1 SEL-751 Feeder Protection Relay Applied Throughout the Power System

Section 2: Installation includes ac and dc connection diagrams for various

applications. The following is a list of other possible application scenarios:

➤ With internal or external RTD module for thermal protection

➤ With arc-flash detection and protection

➤ High-impedance fault (HIF) detection and protection for

feeders

Transformer Bank

Protection

Core-Balance

Current Transformer

Trip

ABC

Distribution Bus

Distributed Generation

Fast Bus Trip Scheme

Utility Distribution

Feeder Protection

and Reclosing

Industrial Distribution

Feeder Protection

ABC

Trip

Distribution Bus

Protection

Trip and

SEL-751
