Schweitzer Engineering Laboratories SEL-751 - Table 4.35 Overvoltage Function

4.98
SEL-751 Relay Instruction Manual Date Code 20170927
Protection and Logic Functions
Group Settings (SET Command)
Table 4.35 Overvoltage Function
Setting Prompt Setting Range
Setting Name :=
Factory De fault
OV TRIP1 LEVEL Off, 2.00–300.00 V 59P1P := OFF
OV TRIP1 DELAY 0.00–120.00 sec 59P1D := 0.50
OV TRIP2 LEVEL Off, 2.00–300.00 V 59P2P := OFF
OV TRIP2 DELAY 0.00–120.00 sec 59P2D := 5.00
PP OV TRIP1 LEVEL Off, 2.00–300.00 V
a
a
Setting range shown is for DELTA_Y := DELTA.
59PP1P := OFF
PP OV TRIP1 LEVEL Off, 2.00–520.00 V
b
b
Setting range shown is for DELTA_Y := WYE.
59PP1P := OFF
PP OV TRIP1 DELAY 0.00–120.00 sec 59PP1D := 0.50
PP OVTRIP2 LEVEL Off, 2.00–300.00 V
a
59PP2P := OFF
PP OV TRIP2 LEVEL Off, 2.00–520.00 V
b
59PP2P := OFF
PP OV TRIP2 DELAY 0.00–120.00 sec 59PP2D := 5.00
ZS OV TRIP1 LVL Off, 2.00–300.00 V 59G1P := OFF
ZS OV TRIP1 DLY 0.00–120.00 sec 59G1D := 0.50
ZS OV TRIP2 LVL Off, 2.00–300.00 V 59G2P := OFF
ZS OV TRIP2 DLY 0.00–120.00 sec 59G2D := 5.00
NSQ OV TRIP1 LVL Off, 2.00–300.00 V 59Q1P := OFF
NSQ OV TRIP1 DLY 0.00–120.00 sec 59Q1D := 0.50
NSQ OV TRIP2 LVL Off, 2.00–300.00 V 59Q2P := OFF
NSQ OV TRIP2 DLY 0.00–120.00 sec 59Q2D := 5.00
UVS LEVEL 1 Off, 2.00–300.00 V 59S1P := OFF
UVS DELAY 1 0.00–120.00 sec 59S1D := 0.50
UVS LEVEL 2 Off, 2.00–300.00 V 59S2P := OFF
UVS DELAY 2 0.00–120.00 sec 59S2D := 0.50
