7.62
SEL-751 Relay Instruction Manual Date Code 20170927
Communications
Communications Protocols
COMTRADE Directory (Available Only for MMS)
When using MMS file transfer, conveniently retrieve all of the COMTRADE
files from the COMTRADE directory. Note that the COMTRADE files are
also available in the Events directory. Refer to Table 7.59 for all the files
available in the COMTRADE directory.
HMI Directory (Read and Write)
Use the HMI directory to retrieve the diagnostic information and the setting
files that apply to the touchscreen. Refer to Table 7.56 for all the files available
in the HMI directory.
Ymodem File Structure
All the files available (see Table 7 .60) for Ymodem protocol are in the root
directory. See FILE Command on page 7.32 for a response to the FIL DIR
command.
Table 7.60 Files Available for Ymodem Protocol (Sheet 1 of 2)
File Name Description
Read
Access
Level
Write
Access
Level
CFG.TXT See Root Directory on page 7.58 1, 2, C N/A
ERR.TXT See Settings Directory (Only Available for FTP) on page 7.59 1, 2, C N/A
SET_ALL.TXT
a
See Settings Directory (Only Available for FTP) on page 7.59 1, 2, C N/A
SET_n.TXT See Settings Directory (Only Available for FTP) on page 7.59 1, 2, C 2, C
SET_C.TXT
a
See Settings Directory (Only Available for FTP) on page 7.59 CC
SET_Dn.TXT See Settings Directory (Only Available for FTP) on page 7.59 1, 2, C 2, C
SET_F.TXT See Settings Directory (Only Available for FTP) on page 7.59 1, 2, C 2, C
SET_G.TXT See Settings Directory (Only Available for FTP) on page 7.59 1, 2, C 2, C
SET_I.TXT See Settings Directory (Only Available for FTP) on page 7.59 1, 2, C 2, C
SET_Ln.TXT See Settings Directory (Only Available for FTP) on page 7.59 1, 2, C 2, C
SET_M.TXT See Settings Directory (Only Available for FTP) on page 7.59 1, 2, C 2, C
SET_Pn.TXT See Settings Directory (Only Available for FTP) on page 7.59 1, 2, C 2, C
SET_R.TXT See Settings Directory (Only Available for FTP) on page 7.59 1, 2, C 2, C
C4_nnnnn.CEV See Events Directory (Read-Only) on page 7.60 1, 2, C N/A
CHF_nnnnn.CEV See Events Directory (Read-Only) on page 7.60 1, 2, C N/A
CR_nnnnn.CEV See Events Directory (Read-Only) on page 7.60 1, 2, C N/A
HF_nnnnn.CFG See Events Directory (Read-Only) on page 7.60 1, 2, C N/A
HF_nnnnn.DAT See Events Directory (Read-Only) on page 7.60 1, 2, C N/A
HF_nnnnn.HDR See Events Directory (Read-Only) on page 7.60 1, 2, C N/A
HR_nnnnn.CFG See Events Directory (Read-Only) on page 7.60 1, 2, C N/A
HR_nnnnn.DAT See Events Directory (Read-Only) on page 7.60 1, 2, C N/A
HR_nnnnn.HDR See Events Directory (Read-Only) on page 7.60 1, 2, C N/A
BRE.TXT See Reports Directory (Read-Only) on page 7.60 1, 2, C N/A
CHISTORY.TXT See Reports Directory (Read-Only) on page 7.60 1, 2, C N/A
CHISTORY_HIF.TXT See Reports Directory (Read-Only) on page 7.60 1, 2, C N/A
HISTORY.TXT See Reports Directory (Read-Only) on page 7.60 1, 2, C N/A
HISTORY_HIF.TXT See Reports Directory (Read-Only) on page 7.60 1, 2, C N/A
