Modbus Map Settings (SET M Command)
Modbus Map Settings (SET M Command)
Modbus User Map
Table 4.108 shows the available settings. See Appendix E: Modbus RTU Com-
munications for additional details.
Touchscreen Settings
The touchscreen settings apply to relays that support the color touchscreen
display and are discussed in Section 9: Bay Control (see Table 9.5).
·
·
·
DNP Analog Output Label Name 6 characters AO_31 := NA
DNP Counter Label Name 11 characters CO_00 := NA
·
·
·
DNP Counter Label Name 11 characters CO_31 := NA
a
See Appendix D: DNP3 Communications for complete list of the DNP Map Labels and factory-
default settings.
Table 4.107 DNP Map Settings
a
(Sheet 2 of 2)
Setting Prompt Setting Range
Setting Name :=
Fac to ry Default
Table 4.108 User Map Register Settings
a
a
See Appendix E: Modbus RTU Communications for Modbus Register Labels and factory-
default settings.
Setting Prompt Setting Range
Setting Name :=
Fac to ry Defa ult
USER REG#1 NA, 1 Modbus Register Label MOD_001 :=
•••
•••
•••
USER REG#125 NA, 1 Modbus Register Label MOD_125 :=
