Schweitzer Engineering Laboratories SEL-751 - Figure 7.26 GOOSE Command Response

7.35
Date Code 20170927 Instruction Manual SEL-751 Relay
Communications
Communications Protocols
An example response to the GOOSE command is shown in Figure 7.26.
=>GOOSE <Enter>
GOOSE Transmit Status
MultiCastAddr Ptag:Vlan AppID StNum SqNum TTL Code
-----------------------------------------------------------------------------
SEL_751_1CFG/LLN0$GO$GPub01
01-0C-CD-01-00-09 4:1 4105 1 117 228
Data Set: SEL_751_1CFG/LLN0$GPDSet01
SEL_751_1CFG/LLN0$GO$NewGOOSEMessage
01-0C-CD-01-00-3E 4:1 62 1 117 227
Data Set: SEL_751_1CFG/LLN0$GPDSet01
SEL_751_1CFG/LLN0$GO$NewGOOSEMessage1
01-0C-CD-01-00-3F 4:1 63 1 117 226
Data Set: SEL_751_1CFG/LLN0$GPDSet01
SEL_751_1CFG/LLN0$GO$NewGOOSEMessage2
01-0C-CD-01-00-40 4:1 64 1 117 214
Data Set: SEL_751_1CFG/LLN0$GPDSet01
SEL_751_1CFG/LLN0$GO$NewGOOSEMessage3
01-0C-CD-01-00-41 4:1 65 1 117 213
Data Set: SEL_751_1CFG/LLN0$GPDSet01
SEL_751_1CFG/LLN0$GO$NewGOOSEMessage4
01-0C-CD-01-00-42 4:1 66 1 117 213
Data Set: SEL_751_1CFG/LLN0$GPDSet01
SEL_751_1CFG/LLN0$GO$NewGOOSEMessage5
01-0C-CD-01-00-43 4:1 67 1 117 205
Data Set: SEL_751_1CFG/LLN0$GPDSet01
SEL_751_1CFG/LLN0$GO$NewGOOSEMessage6
01-0C-CD-01-00-44 4:1 68 1 117 206
Data Set: SEL_751_1CFG/LLN0$GPDSet01
GOOSE Receive Status
MultiCastAddr Ptag:Vlan AppID StNum SqNum TTL Code
-----------------------------------------------------------------------------
SEL_451_1CFG/LLN0$GO$GooseDSet15
01-0C-CD-01-00-14 : 4116 1 2079182 2000
Data Set: SEL_451_1CFG/LLN0$DSet15
SEL_351S_1CFG/LLN0$GO$GPub01
01-0C-CD-01-00-12 : 4114 1 2084274 2000
Data Set: SEL_351S_1CFG/LLN0$GPDSet01
SEL_700G_1CFG/LLN0$GO$GPub01
01-0C-CD-01-00-0A : 4106 2 2075069 2000
Data Set: SEL_700G_1CFG/LLN0$GPDSet01
SEL_710d5_1CFG/LLN0$GO$GPub01
01-0C-CD-01-00-18 : 4120 2 2075091 2000
Data Set: SEL_710d5_1CFG/LLN0$GPDSet01
SEL_710_1CFG/LLN0$GO$GooseDSet13
01-0C-CD-01-00-08 : 4104 2 2030049 2000
Data Set: SEL_710_1CFG/LLN0$DSet13
SEL_710_2CFG/LLN0$GO$GPub01
01-0C-CD-01-00-13 : 19 2 2075484 2000
Data Set: SEL_710_2CFG/LLN0$GPDSet01
Figure 7.26 GOOSE Command Response
