D.25
Date Code 20170927 Instruction Manual SEL-751 Relay
DNP3 Communications
DNP3 Documentation
You can also use the MAP DNP y s <Enter> command to display DNP3
maps, but the parameter y is the port number from 1 to 4. Because Port 1, the
Ethernet port, can support multiple DNP3 sessions, it may have a different
map assigned to each session selected by parameter s for sessions 1 to 5. See
Figure D.4 for an example of a MAP command that shows the same map as in
Figure D.3.
Analog Input Map
AI_00 := IA_MAG
AI_01 := IB_MAG
AI_02 := IC_MAG
…
AI_95 := FREQ
AI_96 := P
AI_97 := Q
AI_98 := S
AI_99 := PF
Analog Output Map
AO_00 := GROUP
AO_01 := RA001
AO_02 := NA
…
AO_29 := NA
AO_30 := RA120
AO_31 := RA128
Counter Map
CO_00 := SC01
CO_01 := SC02
CO_02 := SC03
…
CO_29 := SC30
CO_30 := SC31
CO_31 := SC32
=>>
=>MAP DNP 11 <Enter>
SEL-751 Date: 12/14/2010 Time: 09:33:39
FEEDER RELAY Time Source: Internal
Map 1
Transport TCP
Device IP Address 10.201.5.3
Master IP Address 10.200.0.139
Device DNP TCP and UDP Port 20000
Device DNP Address 15
Master DNP Address 0
Binary Inputs
--------------------------------------------------------------------------------
INDEX POINT LABEL EVENT CLASS SER TIMESTAMP
0 ENABLED 1 No
1 TRIP_LED 1 No
2 TLED_01 1 No
3 TLED_02 1 No
…
97 IN101 1 No
98 IN102 1 No
99 50P1P 1 No
Binary Outputs
--------------------------------------------------------------------------------
INDEX POINT LABEL
0 RB01
1 RB02
2 RB03
…
29 RB30
30 RB31
31 RB32
Figure D.4 Port MAP Command
Figure D.3 Sample Response to SHO DNP Command (Continued)
