7.32
SEL-751 Relay Instruction Manual Date Code 20170927
Communications
Communications Protocols
EVENT Command (Event Reports)
Use the EVE command (see Table 7.16) to view event reports. See Section 10:
Analyzing Events for further details on retrieving and analyzing event reports.
See the HISTORY Command on page 7.37 for details on clearing event
reports.
FILE Command
The FIL command (see Table 7.1 7 ) is intended to be a safe and efficient
means of transferring files between intelligent electronic devices (IEDs) and
external support software (ESS). The FIL command ignores the hide rules and
transfers visible as well as hidden settings, except the settings hidden by a part
number. The FIL command is supported if you connect over serial or Ethernet
ports.
=>>ETH <Enter>
SEL-751 Date: 06/05/2010 Time: 10:41:44
FEEDER RELAY Time Source: Internal
MAC: 00-30-A7-00-75-6A
IP ADDRESS: 192.168.1.2
SUBNET MASK: 255.255.255.0
DEFAULT GATEWAY: 192.168.1.1
LINK SPEED DUPLEX MEDIA
PORT 1A Up 100M Full TX
=>>
Figure 7.25 Ethernet Port (PORT 1) Status Report for the Single Ethernet
Port Option
Table 7.16 EVENT Command (Event Reports)
Command Description Access Level
EVE n Returns the n event report with 4-samples/
cycle data.
1
EVE n R Returns the n event report with raw (unfiltered)
16 samples/cycle analog data and 4 samples/cycle
digital data.
1
Parameter
n Parameter n specifies the event report number to be returned. Use
the HIS command to determine the event report number of the event
you want to display. If n is not specified, the relay displays event
report 1 by default.
Table 7.17 FILE Command
Command Description Access Level
FIL DIR Returns a list of files. 1
FIL READ filename Transfers settings file filename from the relay
to the PC.
1
FIL WRITE filename Transfers settings file filename from the PC to
the relay.
2
FIL SHOW filename Displays contents of the file filename.1
