4.191
Date Code 20170927 Instruction Manual SEL-751 Relay
Protection and Logic Functions
Port Settings (SET P Command)
PORT 2
PORT 3
MODNUM2
a
Modbus TCP Port 2 EMOD > 1
PMOTCP1 PMU Output 1 TCP/IP (Local)
Port Number
PMOTS1 := TCP, UDP_T, or UDP_U
PMOTCP2 PMU Output 2 TCP/IP (Local)
Port Number
PMOTS2 := TCP, UDP_T, or UDP_U
DNPNUM DNPTCP and UDP Port EDNP > 0
SNTPPORT SNTPIP (Local) Port Number ESNTP OFF
a
MODNUM1 and MODNUM2 can have the same port number. The relay displays an error
message if this number matches with the port numbers of other protocols.
Table 4.85 Port Number Settings That Must be Unique (Sheet 2 of 2)
Setting Name Setting Required When
Table 4.86 Fiber-Optic Serial Port Settings
Setting Prompt Setting Range
Setting Name :=
Factory Default
ENABLE PORT Y, N EPORT := Y
PROTOCOL SEL, DNP, MOD, EVMSG, PMU,
MBA, MBB, MB8A, MB8B, MBTA,
MBTB, 103
PROTO := SEL
MAXIMUM ACCESS
LEVEL
1, 2, C MAXACC := 2
SPEED 300–38400 bps SPEED := 9600
DATA BITS 7, 8 bits BITS := 8
PARITY O, E, N PARITY := N
STOP BITS 1, 2 bits STOP := 1
PORT TIME-OUT 0–30 min T_OUT := 5
LANGUAGE ENGLISH, SPANISH LANG :=
ENGLISH
SEND AUTOMESSAGE Y, N AUTO := N
FAST OP MESSAGES Y, N FASTOP := N
MODBUS SLAVE ID 1–247 SLAVEID := 1
NOTE: For additional settings when
PROTO := MBxx, see Table J.5 as well
as M
IRRORED BITS Transmit SELOGIC
Control Equations.
For additional settings when
PROTO := DNP, see Table D.7 for a
complete list of the DNP3 session
settings.
Refer to Appendix G: IEC 60870-5-103
Communications for more information
on IEC 60870-6-103.
NOTE: All port settings are hidden if
the relay is ordered without the Port 2
option. See the SEL-751 MOT for
details.
Table 4.87 Rear-Panel Serial Port (EIA-232) Settings (Sheet 1 of 2)
Setting Prompt Setting Range
Setting Name :=
Factory Default
ENABLE PORT Y, N EPORT := Y
PROTOCOL SEL, DNP, MOD, EVMSG, PMU,
MBA, MBB, MB8A, MB8B, MBTA,
MBTB, 103
PROTO := SEL
MAXIMUM ACCESS
LEVEL
1, 2, C MAXACC := 2
SPEED 300–38400 bps SPEED := 9600
DATA BITS 7, 8 bits BITS := 8
PARITY O, E, N PARITY := N
STOP BITS 1, 2 bits STOP := 1
PORT TIMEOUT 0–30 min T_OUT := 5
NOTE: For additional settings when
PROTO := MBxx, see Table J.5 as well
as M
IRRORED BITS Transmit SELOGIC
Control Equations.
For additional settings when
PROTO := DNP, see Table D.7 for a
complete list of the DNP3 session
settings.
Refer to Appendix G: IEC 60870-5-103
Communications for more information
on IEC 60870-6-103.
