SET.31
of 78
Date _______________ SEL-751 Settings Sheets
M
IRRORED BITS Transmit SELOGIC Control Equations Global Settings (SET G Command)
MIRRORED BITS Transmit SELOGIC Control Equations
(Hidden if PROTO is not MBxx on any of the communications ports)
Global Settings (SET G Command)
General
Event Messenger Points
(Only the points enabled by EMP are visible.)
OUT507 FAIL-SAFE (Y, N) OUT507FS :=
OUT507 :=
OUT508 FAIL-SAFE (Y, N) OUT508FS :=
OUT508 :=
TMB1A :=
TMB2A :=
TMB3A :=
TMB4A :=
TMB5A :=
TMB6A :=
TMB7A :=
TMB8A :=
TMB1B :=
TMB2B :=
TMB3B :=
TMB4B :=
TMB5B :=
TMB6B :=
TMB7B :=
TMB8B :=
PHASE ROTATION (ABC, ACB) PHROT :=
RATED FREQ. (50, 60 Hz) FNOM :=
DATE FORMAT (MDY, YMD, DMY) DATE_F :=
MET CUTOFF THRES (Y, N) METHRES :=
FAULT CONDITION (SELOGIC) FAULT :=
EVE MSG PTS ENABL (N, 1–32) EMP :=
MESSENGER POINT MP01 TRIGGER (OFF, 1 Relay Word bit) MPTR01 :=
MESSENGER POINT MP01 AQ (None, 1 analog quantity) MPAQ01 :=
MESSENGER POINT MP01 TEXT (148 characters) MPTX01 :=
