Schweitzer Engineering Laboratories SEL-751 - Table F.24 Logical Device: CFG (Configuration); Table F.25 PICS for A-Profile Support; Table F.26 PICS for T-Profile Support; Protocol Implementation Conformance Statement

F.42
SEL-751 Relay Instruction Manual Date Code 20170927
IEC 61850 Communications
Protocol Implementation Conformance Statement
Protocol Implementation Conformance Statement
The following tables are as shown in the IEC 61850 standard, Part 8-1,
Section 24. Note that because the standard explicitly dictates which services
and functions must be implemented to achieve conformance, only the optional
services and functions are listed.
TRIPGGIO28 Ind09.stVal–Ind16.stVal 0 Reserved for future use
VBGGIO19 Ind001.stVal–
Ind128.stVal
VB001–VB128 Virtual Bits (VB001 to VB128)
a
MX values contain instantaneous attributes (instMag and instCVal), which are updated whenever the source updates, and other attributes
that are only updated when the source goes outside the data source’s deadband (mag and cVal). Only instantaneous values are shown in
the table.
b
Active data depends on the optional I/O card installed in the slot.
c
Active data depends on the optional arc-flash card installed.
d
Active data depends on the EMV setting.
e
Data validity depends on the relay model and installed card options. Refer to Section 1: Introduction and Specifications for different relay
models and available card options. Refer to Section 5: Metering and Monitoring for the model-dependent metering quantities.
f
Active data depends on the ESC setting.
g
Active data depends on the ELB setting.
h
Active data depends on the ELAT setting.
i
Active data depends on the ESV setting.
Table F.24 Logical Device: CFG (Configuration)
Logical Node Attribute Data Source Comment
Functional Constraint = DC
DevIDLPHD1 PhyNam.model PARTNO Part number
DevIDLPHD1 PhyNam.serNum SER_NUM Serial number
LLN0 NamPlt.swRev FID Firmware revision
Table F.23 Logical Device: ANN (Annunciation) (Sheet 7 of 7)
Logical Node Attribute Data Source Comment
Table F.25 PICS for A-Profile Support
Profile Client Server Value/Comment
A1 Client/Server N Y
A2 GOOSE/GSE management Y Y Only GOOSE, not GSSE
Management
A3 GSSE N N
A4 Time Sync N N
Table F.26 PICS for T-Profile Support
Profile Client Server Value/Comment
T1 TCP/IP N Y
T2 OSI N N
T3 GOOSE/GSE Y Y Only GOOSE, Not GSSE
T4 GSSE N N
T5 Time Sync Y N
