IEC 61850 Communications
Logical Nodes
PROGGIO29 Ind29.stVal–Ind32.stVal AFS5EL–AFS8EL
c
AF Light Input 5–8 excessive ambient light pickup
PROGGIO37 Ind01.stVal–Ind03.stVal THRLA1–THRLA3 Thermal Element 1 alarm—Thermal Element 3 alarm
PROGGIO37 Ind04.stVal–Ind06.stVal THRLT1–THRLT3 Thermal Element 1 trip—Thermal Element 3 trip
PROGGIO37 Ind07.stVal–Ind09.stVal THOVL1–THOVL3 Thermal Element 1 operating current overload—Thermal
Element 3 operating current overload
PROGGIO37 Ind10.stVal THAMBH Ambient temperature measurement health
PROGGIO37 Ind11.stVal 78VSBL Vector shift element block condition
PROGGIO37 Ind12.stVal 78VSO Vector shift element output
PROGGIO37 Ind13.stVal HBL2T Combined-phase second-harmonic block timed out
PROGGIO37 Ind14.stVal HBL5T Combined-phase fifth-harmonic block timed out
PROGGIO37 Ind14.stVal HBL5T Combined-phase fifth-harmonic block timed out
PROGGIO37 Ind15.stVal 52B Circuit breaker N/C contact
RCGGIO30 Ind01.stVal 79RS Reclosing relay in reset state
RCGGIO30 Ind02.stVal 79CY Reclosing relay in reclose cycle state
RCGGIO30 Ind03.stVal 79LO Reclosing relay in lockout state
RCGGIO30 Ind04.stVal–Ind08.stVal SH0–SH4 Reclosing relay shot counter = 0–4
RMBAGGIO8 Ind01.stVal–Ind08.stVal RMB1A–RMB8A Receive M
IRRORED BITS (RMB1A to RMB8A)
RMBBGGIO10 Ind01.stVal–Ind08.stVal RMB1B–RMB8B Receive MIRRORED BITS (RMB1B to RMB8B)
SGGGIO36 Ind01.stVal–Ind04.stVal SG1–SG4 Setting Group 1 to 4 selection
SVGGIO3 Ind01.stVal–Ind32.stVal SV01–SV32
i
SELOGIC Variables (SV01 to SV32)
SVTGGIO4 Ind01.stVal–Ind32.stVal SV01T–SV32T
i
SELOGIC Variable timers (SV01T to SV32T)
TLEDGGIO6 Ind01.stVal ENABLED ENABLED LED
TLEDGGIO6 Ind02.stVal TRIP_LED TRIP LED
TLEDGGIO6 Ind03.stVal–Ind08.stVal TLED_01–TLED_06 Target LEDs TLED_01 to TLED_06
TMBAGGIO9 Ind01.stVal–Ind08.stVal TMB1A–TMB8A Transmit M
IRRORED BITS (TMB1A to TMB8A)
TMBBGGIO11 Ind01.stVal–Ind08.stVal TMB1B–TMB8B Transmit MIRRORED BITS (TMB1B to TMB8B)
TRIPGGIO28 Ind01.stVal AMBTRIP Ambient temperature trip
TRIPGGIO28 Ind02.stVal BRGTRIP Bearing temperature trip
TRIPGGIO28 Ind03.stVal FAULT Indicates fault condition
TRIPGGIO28 Ind04.stVal OTHTRIP Other temperature trip
TRIPGGIO28 Ind05.stVal REMTRIP Remote trip
TRIPGGIO28 Ind06.stVal RTDFLT Asserts when an open or short circuit condition is detected on
any enabled RTD input, or communication with the external
RTD module has been interrupted
TRIPGGIO28 Ind07.stVal ULTRIP Unlatch (auto reset) trip from SEL
OGIC equation
TRIPGGIO28 Ind08.stVal WDGTRIP Winding temperature trip
Table F.23 Logical Device: ANN (Annunciation) (Sheet 6 of 7)
