DNP3 Communications
DNP3 Documentation
DNP3 Documentation
Object List
Table D.9 lists the objects and variations with supported function codes and
qualifier codes available in the SEL-751. The list of supported objects
conforms to the format laid out in the DNP specifications and includes both
supported and unsupported objects for DNP3 implementation Level 2 and
higher and unsupported objects for DNP3 implementation Level 2 only. Those
that are supported include the function and qualifier codes. The objects that
are not supported are shown without any corresponding function and qualifier
codes.
Ta b l e D.9 S E L- 75 1 D N P O b j ec t L i st (Sheet 1 of 6)
Obj. Var. Description
Request
a
Response
b
Funct.
Codes
c
Qual.
Codes
d
Funct.
Codes
c
Qual.
Codes
d
0 211 Device Attributes—User-specific sets of attributes 1 0 129 0,17
0 212 Device Attributes—Master data set prototypes 1 0 129 0,17
0 213 Device Attributes—Outstation data set prototypes 1 0 129 0,17
0 214 Device Attributes—Master data sets 1 0 129 0,17
0 215 Device Attributes—Outstation data sets 1 0 129 0,17
0 216 Device Attributes—Max binary outputs per request 1 0 129 0,17
0 219 Device Attributes—Support for analog output events 1 0 129 0,17
0 220 Device Attributes—Max analog output index 1 0 129 0,17
0 221 Device Attributes—Number of analog outputs 1 0 129 0,17
0 222 Device Attributes—Support for binary output events 1 0 129 0,17
0 223 Device Attributes—Max binary output index 1 0 129 0,17
0 224 Device Attributes—Number of binary outputs 1 0 129 0,17
0 225 Device Attributes—Support for frozen counter events 1 0 129 0,17
0 226 Device Attributes—Support for frozen counters 1 0 129 0,17
0 227 Device Attributes—Support for counter events 1 0 129 0,17
0 228 Device Attributes—Max counter index 1 0 129 0,17
0 229 Device Attributes—Number of counters 1 0 129 0,17
0 230 Device Attributes—Support for frozen analog inputs 1 0 129 0,17
0 231 Device Attributes—Support for analog input events 1 0 129 0,17
0 232 Device Attributes—Max analog input index 1 0 129 0,17
0 233 Device Attributes—Number of analog inputs 1 0 129 0,17
0 234 Device Attributes—Support for double-bit events 1 0 129 0,17
0 235 Device Attributes—Max double-bit binary index 1 0 129 0,17
0 236 Device Attributes—Number of double-bit binaries 1 0 129 0,17
0 237 Device Attributes—Support for binary input events 1 0 129 0,17
0 238 Device Attributes—Max binary input index 1 0 129 0,17
0 239 Device Attributes—Number of binary inputs 1 0 129 0,17
0 240 Device Attributes—Max transmit fragment size 1 0 129 0,17
0 241 Device Attributes—Max receive fragment size 1 0 129 0,17
0 242 Device Attributes—Device manufacturer’s software
version
101290,17
