D.15
Date Code 20170927 Instruction Manual SEL-751 Relay
DNP3 Communications
DNP3 Documentation
0 243 Device Attributes—Device manufacturer’s hardware
version
101290,17
0 245 Device Attributes—User-assigned location name 1 0 129 0,17
0 246 Device Attributes—User assigned ID code/number 1 0 129 0,17
0 247 Device Attributes—User assigned ID code/number 1 0 129 0,17
0 248 Device Attributes—Device serial number 1 0 129 0,17
0 249 Device Attributes—DNP subset and conformance 1 0 129 0,17
0 250 Device Attributes—Device manufacturer’s product
name and model
101290,17
0 252 Device Attributes—Device manufacturer's name 1 0 129 0,17
0 254 Device Attributes—Non-specific all attributes request 1 0 129 0,17
0 255 Device Attributes—List of attribute variations 1 0 129 0,17
1 0 Binary Input—All Variations 1 0, 1, 6, 7, 8, 17, 28
1 1 Binary Input 1 0, 1, 6, 7, 8, 17, 28 129 0, 1, 17, 28
12
e
Binary Input With Status 1 0, 1, 6, 7, 8, 17, 28 129 0, 1, 17, 28
2 0 Binary Input Change—All Variations 1 6, 7, 8
2 1 Binary Input Change Without Time 1 6, 7, 8 129 17, 28
22
e
Binary Input Change With Time 1 6, 7, 8 129, 130 17, 28
2 3 Binary Input Change With Relative Time 1 6, 7, 8 129 17, 28
10 0 Binary Output—All Variations 1 0, 1, 6, 7, 8
10 1 Binary Output
10 2
e
Binary Output Status 1 0, 1, 6, 7, 8 129 0, 1
12 0 Control Block—All Variations
12 1 Control Relay Output Block 3, 4, 5, 6 17, 28 129 echo of request
12 2 Pattern Control Block 3, 4, 5, 6 7 129 echo of request
12 3 Pattern Mask 3, 4, 5, 6 0, 1 129 echo of request
20 0 Binary Counter—All Variations 1, 7, 8, 9, 10 0, 1, 6, 7, 8, 17, 28
20 1 32-Bit Binary Counter 1, 7, 8, 9, 10 0, 1, 6, 7, 8, 17, 28 129 0, 1, 17, 28
20 2 16-Bit Binary Counter 1, 7, 8, 9, 10 0, 1, 6, 7, 8, 17, 28 129 0, 1, 17, 28
20 3 32-Bit Delta Counter
20 4 16-Bit Delta Counter
20 5 32-Bit Binary Counter Without Flag 1, 7, 8, 9, 10 0, 1, 6, 7, 8, 17, 28 129 0, 1, 17, 28
20 6
e
16-Bit Binary Counter Without Flag 1, 7, 8, 9, 10 0, 1, 6, 7, 8, 17, 28 129 0, 1, 17, 28
20 7 32-Bit Delta Counter Without Flag
20 8 16-Bit Delta Counter Without Flag
21 0 Frozen Counter—All Variations
21 1 32-Bit Frozen Counter
21 2 16-Bit Frozen Counter
21 3 32-Bit Frozen Delta Counter
21 4 16-Bit Frozen Delta Counter
Ta b l e D.9 S E L- 75 1 D N P O b j ec t L i st (Sheet 2 of 6)
Obj. Var. Description
Request
a
Response
b
Funct.
Codes
c
Qual.
Codes
d
Funct.
Codes
c
Qual.
Codes
d
