D.16
SEL-751 Relay Instruction Manual Date Code 20170927
DNP3 Communications
DNP3 Documentation
21 5 32-Bit Frozen Counter With Time of Freeze
21 6 16-Bit Frozen Counter With Time of Freeze
21 7 32-Bit Frozen Delta Counter With Time of Freeze
21 8 16-Bit Frozen Delta Counter With Time of Freeze
21 9 32-Bit Frozen Counter Without Flag
21 10 16-Bit Frozen Counter Without Flag
21 11 32-Bit Frozen Delta Counter Without Flag
21 12 16-Bit Frozen Delta Counter Without Flag
22 0 Counter Change Event—All Variations 1 6, 7, 8
22 1 32-Bit Counter Change Event Without Time 1 6, 7, 8 129 17, 28
22 2
e
16-Bit Counter Change Event Without Time 1 6, 7, 8 129, 130 17, 28
22 3 32-Bit Delta Counter Change Event Without Time
22 4 16-Bit Delta Counter Change Event Without Time
22 5 32-Bit Counter Change Event With Time 1 6, 7, 8 129 17, 28
22 6 16-Bit Counter Change Event With Time 1 6, 7, 8 129 17, 28
22 7 32-Bit Delta Counter Change Event With Time
22 8 16-Bit Delta Counter Change Event With Time
23 0 Frozen Counter Event—All Variations
23 1 32-Bit Frozen Counter Event Without Time
23 2 16-Bit Frozen Counter Event Without Time
23 3 32-Bit Frozen Delta Counter Event Without Time
23 4 16-Bit Frozen Delta Counter Event Without Time
23 5 32-Bit Frozen Counter Event With Time
23 6 16-Bit Frozen Counter Event With Time
23 7 32-Bit Delta Counter Change Event With Time
23 8 16-Bit Delta Counter Change Event With Time
30
f
0 Analog Input—All Variations 1 0, 1, 6, 7, 8, 17, 28
30
f
1 32-Bit Analog Input 1 0, 1, 6, 7, 8, 17, 28 129 0, 1, 17, 28
30
f
2 16-Bit Analog Input 1 0, 1, 6, 7, 8, 17, 28 129 0, 1, 17, 28
30
f
3 32-Bit Analog Input Without Flag 1 0, 1, 6, 7, 8, 17, 28 129 0, 1, 17, 28
30
f
4 16-Bit Analog Input Without Flag 1 0, 1, 6, 7, 8, 17, 28 129 0, 1, 17, 28
30
f
5 Short Floating Point Analog Input 1 0, 1, 6, 7, 8, 17, 28 129 0, 1, 17, 28
30
f
6 Long Floating Point Analog Input 1 0, 1, 6, 7, 8, 17, 28 129 0, 1, 17, 28
31 0 Frozen Analog Input—All Variations
31 1 32-Bit Frozen Analog Input
31 2 16-Bit Frozen Analog Input
31 3 32-Bit Frozen Analog Input With Time of Freeze
31 4 16-Bit Frozen Analog Input With Time of Freeze
31 5 32-Bit Frozen Analog Input Without Flag
Ta b l e D.9 S E L- 75 1 D N P O b j ec t L i st (Sheet 3 of 6)
Obj. Var. Description
Request
a
Response
b
Funct.
Codes
c
Qual.
Codes
d
Funct.
Codes
c
Qual.
Codes
d
