Schweitzer Engineering Laboratories SEL-751 - Page 701

D.17
Date Code 20170927 Instruction Manual SEL-751 Relay
DNP3 Communications
DNP3 Documentation
31 6 16-Bit Frozen Analog Input Without Flag
31 7 Short Floating Point Frozen Analog Input
31 8 Long Floating Point Frozen Analog Input
32
f
0 Analog Change Event—All Variations 1 6, 7, 8
32
f
1 32-Bit Analog Change Event Without Time 1 6, 7, 8 129 17, 28
32
f
2 16-Bit Analog Change Event Without Time 1 6, 7, 8 129, 130 17, 28
32
f
3 32-Bit Analog Change Event With Time 1 6, 7, 8 129 17, 28
32
f
4 16-Bit Analog Change Event With Time 1 6, 7, 8 129 17, 28
32
f
5 Short Floating Point Analog Change Event 1 6, 7, 8 129 17, 28
32
f
6 Long Floating Point Analog Change Event 1 6, 7, 8 129 17, 28
32
f
7 Short Floating Point Analog Change Event
With Time
1 6, 7, 8 129 17, 28
32
f
8 Long Floating Point Analog Change Event
With Time
1 6, 7, 8 129 17, 28
33 0 Frozen Analog Event—All Variations
33 1 32-Bit Frozen Analog Event Without Time
33 2 16-Bit Frozen Analog Event Without Time
33 3 32-Bit Frozen Analog Event With Time
33 4 16-Bit Frozen Analog Event With Time
33 5 Short Floating Point Frozen Analog Event
33 6 Long Floating Point Frozen Analog Event
33 7 Short Floating Point Frozen Analog Event With Time
33 8 Long Floating Point Frozen Analog Event With Time
34 0 Analog Deadband—All Variations
34 1
e
16-Bit Analog Input Reporting Deadband Object 1, 2 0, 1, 6, 7, 8, 17, 28 129 0, 1, 17, 28
34 2 32-Bit Analog Input Reporting Deadband Object 1, 2 0, 1, 6, 7, 8, 17, 28 129 0, 1, 17, 28
34 3 Floating Point Analog Input Reporting Deadband
Object
1, 2 0, 1, 6, 7, 8, 17, 28 129 0, 1, 17, 28
40 0 Analog Output Status—All Variations 1 0, 1, 6, 7, 8 129
40 1 32-Bit Analog Output Status 1 0, 1, 6, 7, 8 129 0, 1, 17, 28
40 2
e
16-Bit Analog Output Status 1 0, 1, 6, 7, 8 129 0, 1, 17, 28
40 3 Short Floating Point Analog Output Status 1 0, 1, 6, 7, 8 129 0, 1, 17, 28
40 4 Long Floating Point Analog Output Status 1 0, 1, 6, 7, 8 129 0, 1, 17, 28
41 0 Analog Output Block—All Variations
41 1 32-Bit Analog Output Block 3, 4, 5, 6 17, 28 129 echo of request
41 2
e
16-Bit Analog Output Block 3, 4, 5, 6 17, 28 129 echo of request
41 3 Short Floating Point Analog Output Block 3, 4, 5, 6 17, 28 129 echo of request
50 0 Time and Date—All Variations
50 1 Time and Date 1, 2 7, 8 index = 0 129 07,
quantity = 1
Ta b l e D.9 S E L- 75 1 D N P O b j ec t L i st (Sheet 4 of 6)
Obj. Var. Description
Request
a
Response
b
Funct.
Codes
c
Qual.
Codes
d
Funct.
Codes
c
Qual.
Codes
d
