Schweitzer Engineering Laboratories SEL-751 - Page 702

D.18
SEL-751 Relay Instruction Manual Date Code 20170927
DNP3 Communications
DNP3 Documentation
50 2 Time and Date With Interval
50 3 Time and Date Last Recorded 2 7 quantity = 1 129
51 0 Time and Date CTO—All Variations
51 1 Time and Date CTO
51 2 Unsynchronized Time and Date CTO 129 07,
quantity = 1
52 0 Time Delay—All Variations
52 1 Time Delay, Coarse
52 2 Time Delay, Fine 129 7,
quantity = 1
60 0 All Classes of Data 1, 20, 21 6, 7, 8
60 1 Class 0 Data 1, 20, 21 6, 7, 8
60 2 Class 1 Data 1 6, 7, 8
60 3 Class 2 Data 1, 20, 21 6, 7, 8
60 4 Class 3 Data 1, 20, 21 6, 7, 8
70 1 File Identifier
70 2 Authentication Object
70 3 File Command Object
70 4 File Command Status Object
70 5 File Transport Object
70 6 File Transport Status Object
70 7 File Descriptor Object
80 1 Internal Indications 2 0, 1 index = 7
81 1 Storage Object
82 1 Device Profile
83 1 Private Registration Object
83 2 Private Registration Object Descriptor
90 1 Application Identifier
100 1 Short Floating Point
100 2 Long Floating Point
100 3 Extended Floating Point
101 1 Small Packed Binary-Coded Decimal
101 2 Medium Packed Binary-Coded Decimal
101 3 Large Packed Binary-Coded Decimal
110 All Octet String
111 All Octet String Event
112 All Virtual Terminal Output Block
Ta b l e D.9 S E L- 75 1 D N P O b j ec t L i st (Sheet 5 of 6)
Obj. Var. Description
Request
a
Response
b
Funct.
Codes
c
Qual.
Codes
d
Funct.
Codes
c
Qual.
Codes
d
