Schweitzer Engineering Laboratories SEL-751 - Table E.33 Modbus Register Labels for Use with SET M Command

E.18
SEL-751 Relay Instruction Manual Date Code 20170927
Modbus RTU Communications
Communications Protocol
I
Table E.33 Modbus Register Labels for Use With SET M Command (Sheet 1 of 6)
Register
Address
Label
280 FPGA
281 GPSB
282 HMI
283 RAM
284 ROM
285 CR_RAM
286 NON_VOL
287 CLKSTS
288 CID_FILE
289 RTD
290 P0P9PS
291 P1P2PS
292 P1P5PS
293 P1P8PS
294 P2P5PS
295 P3P3PS
296 P3P75PS
297 P5PS
298 N1P25PS
299 N5PS
300 CLKBAT
301 CARDC
302 CARDD
303 CARDE
304 CARDZ
305 IASTS
306 IBSTS
307 ICSTS
308 INSTS
309 VASTS
310 VBSTS
311 VCSTS
312 VSSTS
313 RLYSTS
314 SER_NUMH
315 SER_NUML
316–319
a
320 IA_MAG
321 IA_ANG
322 IB_MAG
323 IB_ANG
324 IC_MAG
325 IC_ANG
326 IN_MAG
327 IN_ANG
328 IG_MAG
329 IG_ANG
330 I1_MAG
331 I1_ANG
332 IAV
333 3I2
334 UBI
335 VAB_MAG
336 VAB_ANG
337 VBC_MAG
338 VBC_ANG
339 VCA_MAG
340 VCA_ANG
341 VAVE
342 V1_MAG
343 V1_ANG
344 VA_MAG
345 VA_ANG
346 VB_MAG
347 VB_ANG
348 VC_MAG
349 VC_ANG
350 VG_MAG
351 VG_ANG
352 VAVE
353 3V2
354 UBV
355 VS_MAG
356 VS_ANG
357 VDC
358–359
a
360 PA
361 QA
362 SA
363 PFA
364 PB
365 QB
366 SB
367 PFB
368 PC
369 QC
370 SC
371 PFC
372 P
373 Q
374 S
375 PF
376 FREQ
377 FREQS
378–379
a
380 MWH3PIH
381 MWH3PIL
382 MWH3POH
383 MWH3POL
384 MVRH3PIH
385 MVRH3PIL
386 MVRH3POH
387 MVRH3POL
388 MVAH3PH
Register
Address
Label
389 MVAH3PL
390 ENRGY_S
391 ENRGYMN
392 ENRGY_H
393 ENRGY_D
394 ENRGYMO
395 ENRGY_Y
396–399
a
400 RTDWDGMX
401 RTDBRGMX
402 RTDAMB
403 RTDOTHMX
404 RTD1
405 RTD2
406 RTD3
407 RTD4
408 RTD5
409 RTD6
410 RTD7
411 RTD8
412 RTD9
413 RTD10
414 RTD11
415 RTD12
416–419
a
420 LSENS1
421 LSENS2
422 LSENS3
423 LSENS4
424 LSENS5
425 LSENS6
426 LSENS7
427 LSENS8
428–429
a
430 IARMS
431 IBRMS
432 ICRMS
433 INRMS
434 VARMS
435 VBRMS
436 VCRMS
437 VABRMS
438 VBCRMS
439 VCARMS
440 VSRMS
441–449
a
450 IAD
451 IBD
452 ICD
453 IGD
454 3I2D
455 IAPD
Register
Address
Label
456 IBPD
457 ICPD
458 IGPD
459 3I2PD
460 PDEM_R_S
461 PDEM_RMN
462 PDEM_R_H
463 PDEM_R_D
464 PDEM_RMO
465 PDEM_R_Y
466–469
a
470 INTT
471 EXTT
472 INTIA
473 EXTIA
474 INTIB
475 EXTIB
476 INTIC
477 EXTIC
478 WEARA
479 WEARB
480 WEARC
481 BRKR_R_S
482 BRKR_RMN
483 BRKR_R_H
484 BRKR_R_D
485 BRKR_RMO
486 BRKR_R_Y
487–489
a
490 AI301H
491 AI301L
492 AI302H
493 AI302L
494 AI303H
495 AI303L
496 AI304H
497 AI304L
498 AI305H
499 AI305L
500 AI306H
501 AI306L
502 AI307H
503 AI307L
504 AI308H
505 AI308L
506 AI401H
507 AI401L
508 AI402H
509 AI402L
510 AI403H
511 AI403L
512 AI404H
Register
Address
Label
513 AI404L
514 AI405H
515 AI405L
516 AI406H
517 AI406L
518 AI407H
519 AI407L
520 AI408H
521 AI408L
522 AI501H
523 AI501L
524 AI502H
525 AI502L
526 AI503H
527 AI503L
528 AI504H
529 AI504L
530 AI505H
531 AI505L
532 AI506H
533 AI506L
534 AI507H
535 AI507L
536 AI508H
537 AI508L
538–539
a
540 MV01H
541 MV01L
542 MV02H
543 MV02L
544 MV03H
545 MV03L
546 MV04H
547 MV04L
548 MV05H
549 MV05L
550 MV06H
551 MV06L
552 MV07H
553 MV07L
554 MV08H
555 MV08L
556 MV09H
557 MV09L
558 MV10H
559 MV10L
560 MV11H
561 MV11L
562 MV12H
563 MV12L
564 MV13H
565 MV13L
Register
Address
Label
