3.4
SEL-751 Relay Instruction Manual Date Code 20170927
PC Software
Settings Database Management and Drivers
Verify proper communications with the relay by opening a terminal window,
pressing <Enter> a few times, and verifying that a prompt is received. If a
prompt is not received, verify proper setup.
Terminal Logging
To create a file that contains all terminal communications with the relay, select
Terminal Logging in the Communications > Logging menu, and specify a
file at the prompt. QuickSet records communications events and errors in this
file. Click Communications > Logging > Connection Log to view the log.
Clear the log by selecting Communications > Logging > Clear Connection
Log.
Drivers and Part
Number
After clicking Communications > Terminal, access the relay at Access
Level 1. Issue the ID command to receive an identification report, as shown in
Figure 3.5.
Locate and record the Z-number (Z001001) in the FID string. The first portion
of the Z-number (Z001…) determines the QuickSet relay settings driver
version when you are creating or editing relay settings files. The use of the
Device Editor driver version is discussed in more detail later in this section—
see Settings Editor (Editor Mode) on page 3.9. Compare the part number
(
PARTNO=7510XXXXXXXXXXXXXX) with the Model Option Table (MOT) to
ensure the correct relay configuration. The SEL display package version can
be found in Table A.3. The customer display package (CDP) version has a
unique ID code based on the total number of seconds from
1/1/2000 to the time stamp when the Bay Screen project file was created.
Settings Database Management and Drivers
ACSELERATOR QuickSet uses a database to save relay settings. QuickSet
contains sets of all settings files for each relay specified in the Database
Manager. Choose appropriate storage backup methods and a secure location
for storing database files.
=ID <Enter>
"FID=SEL-751-X397-V0-Z007003-D20170305","08BC"
"BFID=BOOTLDR-R500-V0-Z000000-D20090925","0952"
"CID=9B42","025E"
"DEVID=SEL-751","0408"
"DEVCODE=77","0316"
"PARTNO=751001B6X3X7183021X","06D9"
"CONFIG=11251201","03F0"
"SEL DISPLAY PACKAGE=1.0.32768.873","086A"
"CUSTOMER DISPLAY PACKAGE=1.542556555","099A"
"iedName =TEMPLATE","05DC"
"type =SEL_751","04B0"
"configVersion =ICD-751-R100-V0-Z001001-D20070326","0D75"
=
Figure 3.5 Device Response to the ID Command
NOTE: The SEL display package and
customer display package versions
are only displayed in the touchscreen
display model.
