Schweitzer Engineering Laboratories SEL-751

To Next Page

To Previous Page

xxx

SEL-751 Relay Instruction Manual Date Code 20170927

Preface

Safety Information

Product Labels

The following labels are the product labels for the high voltage and low

voltage power supply options for the two-line display and the touchscreen

display. The labels are located on the left side panel of the product. The labels

show the serial number, model number, and the ratings of the product.

Product Labels for the SEL-751 With the Two-Line Display

(High-Voltage Supply)

(Low-Voltage Supply)
