SEL-751 Settings Sheets Date________________
Group Settings (SET Command) Maximum Phase Time-Overcurrent
SEL-751 Relay Instruction Manual Date Code 20170927
Maximum Phase Time-Overcurrent
Negative-Sequence Time-Overcurrent
EM RESET DELAY (Y, N) (Hidden if 51BP := OFF) 51BRS :=
CONST TIME ADDER (0.00–1.00 s) (Hidden if 51BP := OFF) 51BCT :=
MIN RESPONSE TIM (0.00–1.00 s) (Hidden if 51BP := OFF) 51BMR :=
TOC TRQ CONTROL (SELOGIC) (Hidden if 51BP := OFF) 51BTC :=
TOC TRIP LVL (OFF, 0.25–24.00 A {5 A nom}, 0.05–4.80 A {1 A nom}) 51CP :=
TOC CURVE SEL (U1, U2, U3, U4, U5, C1, C2, C3, C4, C5)
(Hidden if 51CP := OFF) 51CC :=
TOC TIME DIAL (0.50–15.00 {if 51CC := U_}, 0.01–1.50 {if 51CC := C_})
(Hidden if 51CP := OFF) 51CTD :=
EM RESET DELAY (Y, N) (Hidden if 51CP := OFF) 51CRS :=
CONST TIME ADDER (0.00–1.00 s) (Hidden if 51CP := OFF) 51CCT :=
MIN RESPONSE TIM (0.00–1.00 s) (Hidden if 51CP := OFF) 51CMR :=
TOC TRQ CONTROL (SELOGIC) (Hidden if 51CP := OFF) 51CTC :=
TOC TRIP LVL (OFF, 0.25–24.00 A {5 A nom}, 0.05–4.80 A {1 A nom}) 51P1P :=
TOC CURVE SEL (U1, U2, U3, U4, U5, C1, C2, C3, C4, C5)
(Hidden if 51P1P := OFF) 51P1C :=
TOC TIME DIAL (0.50–15.00 {if 51P1C := U_},
0.01–1.50 {if 51P1C := C_}) (Hidden if 51P1P := OFF) 51P1TD :=
EM RESET DELAY (Y, N) (Hidden if 51P1P := OFF) 51P1RS :=
CONST TIME ADDER (0.00–1.00 s) (Hidden if 51P1P := OFF) 51P1CT :=
MIN RESPONSE TIM (0.00–1.00 s) (Hidden if 51P1P := OFF) 51P1MR :=
TOC TRQ CONTROL (SELOGIC) (Hidden if 51P1P := OFF) 51P1TC :=
TOC TRIP LVL (OFF, 0.25–24.00 A {5 A nom}, 0.05–4.80 A {1 A nom}) 51P2P :=
TOC CURVE SEL (U1, U2, U3, U4, U5, C1, C2, C3, C4, C5)
(Hidden if 51P2P := OFF) 51P2C :=
TOC TIME DIAL (0.50–15.00 {if 51P2C := U_}, 0.01–1.50 {if 51P2C := C_})
(Hidden if 51P2P := OFF) 51P2TD :=
EM RESET DELAY (Y, N) (Hidden if 51P2P := OFF) 51P2RS :=
CONST TIME ADDER (0.00–1.00 s) (Hidden if 51P2P := OFF) 51P2CT :=
MIN RESPONSE TIM (0.00–1.00 s) (Hidden if 51P2P := OFF) 51P2MR :=
TOC TRQ CONTROL (SELOGIC) (Hidden if 51P2P := OFF) 51P2TC :=
TOC TRIP LVL (OFF, 0.25–24.00 A {5 A nom}, 0.05–4.80 A {1 A nom}) 51QP :=
TOC CURVE SEL (U1, U2, U3, U4, U5, C1, C2, C3, C4, C5)
(Hidden if 51QP := OFF) 51QC :=
TOC TIME DIAL (0.50–15.00 {if 51QC := U_},
0.01–1.50 {if 51QC := C_}) (Hidden if 51QP := OFF) 51QTD :=
EM RESET DELAY (Y, N) (Hidden if 51QP := OFF) 51QRS :=
CONST TIME ADDER (0.00–1.00 s) (Hidden if 51QP := OFF) 51QCT :=
MIN RESPONSE TIM (0.00–1.00 s) (Hidden if 51QP := OFF) 51QMR :=
TOC TRQ CONTROL (SELOGIC) (Hidden if 51QP := OFF) 51QTC :=
