SEL-751 Settings Sheets Date________________
Group Settings (SET Command) Overvoltage
SEL-751 Relay Instruction Manual Date Code 20170927
Overvoltage
(Hidden if Slot Z = Ax)
OV TRIP1 LEVEL (OFF, 2.00–300.00 V) (Hidden if DELTA_Y = DELTA) 59P1P :=
OV TRIP1 DELAY (0.00–120.00 s) (Hidden if 59P1P := OFF or
if DELTA_Y = DELTA) 59P1D :=
OV TRIP2 LEVEL (OFF, 2.00–300.00 V) (Hidden if DELTA_Y = DELTA) 59P2P :=
OV TRIP2 DELAY (0.00–120.00 s) (Hidden if 59P2P := OFF or
if DELTA_Y = DELTA) 59P2D :=
PP OV TRIP1 LEVEL (OFF, 2.00–300.00 V [DELTA_Y := DELTA] or 2.00–520.00 V
[DELTA_Y := WYE]) (Hidden if SINGLEV = Y and DELTA_Y= WYE) 59PP1P :=
PP OV TRIP1 DELAY (0.00–120.00 s) (Hidden if 59PP1P := OFF) 59PP1D :=
PP OV TRIP2 LEVEL (OFF, 2.00–300.00 V [DELTA_Y := DELTA] or 2.00–520.00 V
[DELTA_Y := WYE]) (Hidden if SINGLEV := Y and DELTA_Y = WYE) 59PP2P :=
PP OV TRIP2 DELAY (0.00–120.00 s) (Hidden if 59PP2P := OFF) 59PP2D :=
ZS OV TRIP1 LVL (OFF, 2.00–300.00 V) (Hidden if DELTA_Y = DELTA or
SINGLEV := Y) 59G1P :=
ZS OV TRIP1 DLY (0.00–120.00 s) (Hidden if 59G1P := OFF; hidden
if DELTA_Y = DELTA or SINGLEV := Y) 59G1D :=
ZS OV TRIP2 LVL (OFF, 2.00–300.00 V) (Hidden if DELTA_Y = DELTA or
SINGLEV := Y) 59G2P :=
ZS OV TRIP2 DLY (0.00–120.00 s) (Hidden if 59G2P := OFF; hidden
if DELTA_Y = DELTA or SINGLEV := Y) 59G2D :=
NSQ OV TRIP1 LVL (OFF, 2.00–300.00 V) (Hidden if SINGLEV = Y) 59Q1P :=
NSQ OV TRIP1 DLY (0.00–120.00 s) (Hidden if 59Q1P := OFF; hidden
if SINGLEV = Y) 59Q1D :=
NSQ OV TRIP2 LVL (OFF, 2.00–300.00 V) (Hidden if SINGLEV = Y) 59Q2P :=
NSQ OV TRIP2 DLY (0.00–120.00 s) (Hidden if 59Q2P := OFF; hidden
if SINGLEV = Y) 59Q2D :=
OVS LEVEL 1 (OFF, 2.00–300.00 V) (Shown if Slot E = 70 or L0) 59S1P :=
OVS DELAY 1 (0.00–120.00 s) (Hidden if 59S1P := OFF) 59S1D :=
OVS LEVEL 2 (OFF, 2.00–300.00 V) (Shown if Slot E = 70 or L0) 59S2P :=
OVS DELAY 2 (0.00–120.00 s) (Hidden if 59S2P := OFF) 59S2D :=
