Date Code 20170927 Instruction Manual SEL-751 Relay
SET.19
of 78
Date _______________ SEL-751 Settings Sheets
SEL
OGIC Enables Logic Settings (SET L Command)
Logic Settings (SET L Command)
SELOGIC Enables
Latch Bits Equations
RST TM FROM LO (0.00–3000.00 s) 79RSLD :=
RECLS SUPV TIME (OFF, 0.00–3000.00 s) (Forced to OFF if E79 := N) 79CLSD :=
RECLOSE INITIATE (SELOGIC) 79RI :=
RCLS INIT SUPVSN (SELOGIC) 79RIS :=
DRIVE-TO-LOCKOUT (SELOGIC) 79DTL :=
DRIVE-TO-LSTSHOT (SELOGIC) 79DLS :=
SKIP SHOT (SELOGIC) 79SKP :=
STALL OPN INTRVL (SELOGIC) 79STL :=
BLOCK RESET TMNG (SELOGIC) 79BRS :=
SEQ COORDINATION (SELOGIC) 79SEQ :=
RCLS SUPERVISION (SELOGIC) 79CLS :=
SELOGIC LATCHES (N, 1–32) ELAT :=
SV/TIMERS (N, 1–32) ESV :=
SELOGIC COUNTERS (N, 1–32) ESC :=
MATH VARIABLES (N, 1–32) EMV :=
SET01 :=
RST01 :=
SET02 :=
RST02 :=
SET03 :=
RST03 :=
SET04 :=
RST04 :=
SET05 :=
RST05 :=
SET06 :=
RST06 :=
SET07 :=
RST07 :=
SET08 :=
RST08 :=
SET09 :=
RST09 :=
SET10 :=
RST10 :=
